| Connection technology | 1-wire |
| Number of channels | 8 inputs + 8 outputs |
| Nominal voltage | 24 V DC (-15 %/+20 %) |
| “0” signal voltage | -3…+5 V (IEC 61131-2, type 1/3) |
| “1” signal voltage | 11…30 V (IEC 61131-2, type 1/3) |
| Input current | typ. 3 mA (EN 61131-2, type 1/3) |
| Input filter | typ. < 1 µs |
| Internal sampling/execution | < 10…40 µs, corresponds to 100…25 k detectable edges/s, dependent on configuration |
| Distributed clock precision | << 1 µs |
| Distributed clocks | yes |
| Load type | ohmic, inductive, lamp load |
| Max. output current | 0.5 A (short-circuit proof) per channel |
| Output stage | push |
| Reverse voltage protection | yes |
| Breaking energy | < 150 mJ/channel |
| Switching times | typ. TON: < 1 µs, typ. TOFF: < 1 µs |
| Current consumption power contacts | typ. 30 mA + load |
| Current consumption E-bus | typ. 130 mA |
| Electrical isolation | 500 V (E-bus/field potential) |
| Configuration | no address or configuration setting |
| Conductor types | solid wire, stranded wire and ferrule |
| Conductor connection | solid wire conductors: direct plug-in technique; stranded wire conductors and ferrules: spring actuation by screwdriver |
| Rated cross-section | solid wire: 0.08…1.5 mm²; stranded wire: 0.25…1.5 mm²; ferrule: 0.14…0.75 mm² |
| Special features | multi-timestamping, auto activation |
| Weight | approx. 55 g |
| Operating/storage temperature | 0…+55 °C/-25…+85 °C |
| Relative humidity | 95 %, no condensation |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. class/installation pos. | IP 20/variable (see documentation) |
| Approvals/markings | CE, UL |
