Các sản phẩm được gắn thẻ 'Động cơ bước 5 phase'

Động Cơ Bước 5 Phase Autonics A63K-G5913W

Basic Step Angle [FULL/HALF] : 0.72º/0.36º
Max. holding torque : 63kgf.cm
Rotor Moment Of Inertia : 4000g·cm²
Winding Resistance : 0.86Ω
Rated current : 2.8A/Phase
Wire connection : Pentagon
Protection structure : IP30

Mua Ngay :

Động Cơ Bước 5 Phase Autonics A63K-M5913

Basic Step Angle [FULL/HALF] : 0.72º/0.36º
Max. holding torque : 63kgf.cm
Rotor Moment Of Inertia : 4000g·cm²
Winding Resistance : 3.92Ω
Rated current : 1.4A/Phase
Wire connection : Pentagon
Protection structure : IP30

Mua Ngay :

Động Cơ Bước 5 Phase Autonics AH21K-M596

Basic Step Angle [FULL/HALF] : 0.72º/0.36º
Max. holding torque : 21kgf.cm
Rotor Moment Of Inertia : 1400g·cm²
Winding Resistance : 1.76Ω
Rated current : 1.4A/Phase
Wire connection : Pentagon
Protection structure : IP30

Mua Ngay :

Động Cơ Bước 5 Phase Autonics A63K-M5913-B

Basic Step Angle [FULL/HALF] : 0.72º/0.36º
Max. holding torque : 63kgf.cm
Rotor Moment Of Inertia : 4000g·cm²
Winding Resistance : 3.92Ω
Rated current : 1.4A/Phase
Wire connection : Pentagon
Protection structure : IP30

Mua Ngay :

Động Cơ Bước 5 Phase Autonics AH8K-M566

Basic Step Angle [FULL/HALF] : 0.72º/0.36º
Max. holding torque : 8.3kgf.cm
Rotor Moment Of Inertia : 280g·cm²
Winding Resistance : 1.1Ω
Rated current : 1.4A/Phase
Wire connection : Pentagon
Protection structure : IP30

Mua Ngay :

Động Cơ Bước 5 Phase Autonics A1K-S543W

Basic Step Angle [FULL/HALF] : 0.72º/0.36º
Max. holding torque : 1.3kgf.cm
Rotor Moment Of Inertia : 35g·cm²
Winding Resistance : 1.7Ω
Rated current : 0.75A/Phase
Wire connection : Pentagon
Protection structure : IP30

Mua Ngay :

Động Cơ Bước 5 Phase Autonics A200K-G599-G10

Basic Step Angle [FULL/HALF] : 0.072º/0.036º
Max. allowable torque : 200kgf.cm
Rotor Moment Of Inertia : 2700g·cm²
Winding Resistance : 0.58Ω
Rated current : 2.8A/Phase
Wire connection : Pentagon
Protection structure : IP30

Mua Ngay :

Động Cơ Bước 5 Phase Autonics A140K-G599-GB5

Basic Step Angle [FULL/HALF] : 0.144º/0.072º
Max. allowable torque : 140kgf.cm
Rotor Moment Of Inertia : 2700g·cm²
Winding Resistance : 0.58Ω
Rated current : 2.8A/Phase
Wire connection : Pentagon
Protection structure : IP30

Mua Ngay :

Động Cơ Bước 5 Phase Autonics A8K-S566W-S

Basic Step Angle [FULL/HALF] : 0.72º/0.36º
Max. holding torque : 8.3kgf.cm
Rotor Moment Of Inertia : 280g·cm²
Winding Resistance : 4Ω
Rated current : 0.75A/Phase
Wire connection : Standard
Protection structure : IP30

Mua Ngay :
