| Product characteristics | | |
| Measuring range of vibration [g] | 0…25 | |
| Frequency range [Hz] | 0…6000 | |
| Measuring principle | capacitive | |
| Application | | |
| Application | vibration sensor to ISO 10816 | |
| Self-test function | yes | |
| Heartbeat function | yes | |
| Electrical data | | |
| Operating voltage [V] | 9.6…30 DC; (or via USB (switching outputs not active)) | |
| Current consumption [mA] | < 70 | |
| Protection class | III | |
| Reverse polarity protection | yes | |
| Sensor type | micromechanical accelerometer | |
| Inputs / outputs | | |
| Total number of inputs and outputs | 3; (configurable) | |
| Number of inputs and outputs | Number of analogue inputs: 1; Number of digital outputs: 2; Number of analogue outputs: 1 | |
| Inputs | | |
| Number of analogue inputs | 1 | |
| Analogue input (current) [mA] | 4…20 | |
| Outputs | | |
| Output signal | switching signal; analogue signal | |
| Number of digital outputs | 2 | |
| Max. voltage drop switching output DC [V] | 2 | |
| Minimum load current [mA] | 100 | |
| Number of analogue outputs | 1 | |
| Analogue current output [mA] | 4…22 | |
| Max. load [Ω] | 9,6…17 V: 150; 17…30 V: 500 | |
| Factory setting | switching output: normally closed | |
| switch point pre-alarm: 2,8 mm/s | |
| switch point main alarm: 4,5 mm/s | |
| Frequency range: 10…1000 Hz | |
| measuring method: RMS | |
| unit: mm/s | |
| Short-circuit protection | yes | |
| Overload protection | yes | |
| Measuring/setting range | | |
| Measuring range of vibration [g] | 0…25 | |
| Frequency range [Hz] | 0…6000 | |
| Measuring principle | capacitive | |
| Number of measurement axes | 1 | |
| Accuracy / deviations | | |
| Measuring error [% of the final value] | ± 3% | |
| Interfaces | | |
| Communication interface | USB | |
| Operating conditions | | |
| Ambient temperature [°C] | -30…60 | |
| Storage temperature [°C] | -30…85 | |
| Protection | IP 67 | |
| Mechanical data | | |
| Weight [g] | 286.5 | |
| Type of mounting | mounting set M5/M8 | |
| Dimensions [mm] | 36 x 37.6 x 62.4 | |
| Materials | housing: diecast zinc nickel-plated | |
| Tightening torque [Nm] | 7 | |
| Mechanische Überlastfestigkeit [g] | 100 | |
| Displays / operating elements | | |
| Display | function | 6 x LED, green |
| pre-alarm | 1 x LED, yellow |
| main alarm | 1 x LED, red |
| measured values | 7-segment LED display, red / yellow / green 4-digit |
| Operating elements | 2 | pushbuttons |
| Data memories | | |
| History memory | yes | |
| Data memory type | ring memory; FIFO | |
| Real-time clock | yes; UTC, battery buffered | |
| Memory location | internal | |
| Memory interval | min. 1 s | |
| Memory size | 686774 data records | |
| Accessories | | |
| Items supplied | Spring washer | |
| screw | |
| adapters: 1 x M8 x M5 | |
| Remarks | | |
| Pack quantity | 1 pcs. | |
| Electrical connection – Process connection | |
| Connector: 1 x M12 | |
| Electrical connection – USB | | |
| Connector: 1 x M8 | |
