1SBN030111R1000

Name: 1SBN030111R1000
SKU: 1SBN030111R1000
Price: 212500.00 VND
Availability: InStock

1SBN030111R1000
SKU: 1SBN030111R1000
Hãng sản xuất: ABB
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Chứng từ: CO/CQ, hóa đơn VAT

Mua Ngay :

nhà chế tạo: ABB

SKU: 1SBN030111R1000

Ngày giao hàng: 1-3 days

212.500 ₫

Số lượng:

Connecting Capacity Auxiliary Circuit:	Flexible with Ferrule 1/2x 0.75 … 2.5 mm² Flexible with Insulated Ferrule 2x 0.75 … 1.5 mm² Flexible with Insulated Ferrule 1x 0.75 … 2.5 mm² Rigid Solid 1/2x 1 … 2.5 mm² Rigid Stranded 1/2x 1 … 2.5 mm²
Maximum Electrical Switching Frequency:	1200 cycles per hour
Maximum Mechanical Switching Frequency:	1800 cycles per hour
Mechanical Durability:	5 million
Number of Auxiliary Contacts NC:	2
Number of Auxiliary Contacts NO:	0
Number of Poles:	2
Rated Impulse Withstand Voltage (U_imp):	6 kV
Rated Insulation Voltage (U_i):	acc. to IEC 60947-5-1 690 V
Standards:	IEC/EN 60947-5-1, UL 60947-1, UL 60947-4-1, CSA C22.2 No. 60947-1-13, CSA C22.2 No. 60947-4-1
Suitable For:	AF09 AF09Z AF12 AF12Z AF16 AF16Z AF26 AF26Z AF30 AF30Z AF38 AF38Z AFC09 AFC12 AFC16 AFC26 AFC30 AFC38 AF09B AF09ZB AF12B AF12ZB AF16B AF16ZB AF26B AF26ZB AF30B AF30ZB AF38B AF38ZB
Terminal Type:	Screw Terminals
Tightening Torque:	Auxiliary Circuit 1.2 NÂ·m
Wire Stripping Length:	Auxiliary Circuit 10 mm
