EL1252 | EtherCAT Terminal, 2-channel digital input, 24 V DC, 1 µs, timestamp

Name: EL1252 | EtherCAT Terminal, 2-channel digital input, 24 V DC, 1 µs, timestamp
SKU: EL1252
Price: 1000.00 VND
Availability: InStock

EL1252 | EtherCAT Terminal, 2-channel digital input, 24 V DC, 1 µs, timestamp
SKU: EL1252
Hãng sản xuất: Beckhoff
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Chứng từ: CO/CQ, hóa đơn VAT

Mua Ngay :

SKU: EL1252

Ngày giao hàng: 1-3 days

1.000 ₫

Số lượng:

EL1252 | EtherCAT Terminal, 2-channel digital input, 24 V DC, 1 µs, timestamp

Thông Tin Chi Tiết Sản Phẩm

Technical data	EL1252, ES1252
Connection technology	4-wire
Specification	similar to EN 61131-2, type 3, “0”: -3…5 V DC, “1”: 11…30 V DC, typ. 3 mA input current
Number of inputs	2
Nominal voltage	24 V DC (-15 %/+20 %)
“0” signal voltage	-3…+5 V (similar to EN 61131-2, type 3)
“1” signal voltage	11…30 V (similar to EN 61131-2, type 3)
Input current	typ. 3 mA (similar to EN 61131-2, type 3)
Input filter	typ. < 1 µs
Resolution timestamp	1 ns
Precision of timestamp in the terminal	10 ns (+ input delay)
Distributed clock precision	<< 1 µs
Input delay TON/TOFF	< 1 µs
Distributed clocks	yes
Time resolution signal	1 ns
Current consumption power contacts	typ. 6 mA + load
Current consumption E-bus	typ. 110 mA
Electrical isolation	500 V (E-bus/field potential)
Bit width in the process image	2 x input + 2 x 16 byte timestamp
Configuration	no address or configuration setting
Special features	timestamping, latch last edge
Weight	approx. 55 g
Operating/storage temperature	-25…+60 °C/-40…+85 °C
Relative humidity	95 %, no condensation
Vibration/shock resistance	conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission	conforms to EN 61000-6-2/EN 61000-6-4
Protect. class/installation pos.	IP 20/variable
Pluggable wiring	for all ESxxxx terminals
Approvals/markings	CE, UL, ATEX
Ex marking	II 3 G Ex nA IIC T4 Gc
