EL7201 | EtherCAT Terminal, 1-channel motion interface, servo motor, 48 V DC, 2.8 A, resolver

Name: EL7201 | EtherCAT Terminal, 1-channel motion interface, servo motor, 48 V DC, 2.8 A, resolver
SKU: EL7201
Price: 1000.00 VND
Availability: InStock

EL7201 | EtherCAT Terminal, 1-channel motion interface, servo motor, 48 V DC, 2.8 A, resolver
SKU: EL7201
Hãng sản xuất: Beckhoff
Chất lượng: Mới 100%
Bảo hành: Chính hãng
Chứng từ: CO/CQ, hóa đơn VAT

Mua Ngay :

nhà chế tạo: Beckhoff

SKU: EL7201

Ngày giao hàng: 1-3 days

1.000 ₫

Số lượng:

EL7201 | EtherCAT Terminal, 1-channel motion interface, servo motor, 48 V DC, 2.8 A, resolver

Thông Tin Chi Tiết Sản Phẩm

Technical data	EL7201
Technology	compact drive technology
Connection method	direct motor connection + feedback
Number of inputs	1 x feedback
Load type	permanent magnet-excited three-phase synchronous motor
Number of channels	1
Number of outputs	1 x servomotor, 1 x motor brake
Supply voltage electronics	24 V DC (via power contacts)
Supply voltage power	8…48 V DC (external)
Output current (rms)	2.8 A
Peak current (rms)	max. 5.7 A for 1 s
Performance increase	yes, through ZB8610 fan cartridge
Output current with ZB8610 (rms)	max. 4.5 A
Peak current with ZB8610 (rms)	max. 9.0 A for 1 s
Rotating field frequency	0…599 Hz
PWM clock frequency	16 kHz
Current controller frequency	32 kHz
Rated speed controller frequency	16 kHz
Output voltage motor brake	24 V DC
Output current motor brake	max. 0.5 A
Current consumption power contacts	typ. 50 mA + holding current motor brake
Current consumption E-bus	typ. 120 mA
Distributed clocks	yes
Special features	compact (only 12 mm wide), system-integrated
Electrical isolation	500 V (E-bus/field potential)
Weight	approx. 60 g
Operating/storage temperature	0…+55 °C/-25…+85 °C
Relative humidity	95 %, no condensation
EMC immunity/emission	conforms to EN 61000-6-2/EN 61000-6-4
Vibration/shock resistance	conforms to EN 60068-2-6/EN 60068-2-27
Protect. class/installation pos.	IP 20/see documentation
Approvals/markings	CE, UL
