Các sản phẩm được gắn thẻ 'Cảm biến áp suất'

Cảm biến áp suất Autonics PSB-01-M5

Applicable fluid : (Pneumatic type) Air, Non-corrosive gas
Pressure port : M5
Connection type : Cable type(cable type cable: 2m)
Pressure type : Standard pressure
Rated pressure range : 0.0 to 100.0kPa
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Current consumption : Max. 50mA
Protection structure : IP40

Mua Ngay :

Cảm biến áp suất Autonics PSB-01P-M5

Applicable fluid : (Pneumatic type) Air, Non-corrosive gas
Pressure port : M5
Connection type : Cable type(cable type cable: 2m)
Pressure type : Standard pressure
Rated pressure range : 0.0 to 100.0kPa
Control output_PNP open collector : PNP open collector
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Current consumption : Max. 50mA
Protection structure : IP40

Mua Ngay :

Cảm biến áp suất Autonics PSB-1-M5

Applicable fluid : (Pneumatic type) Air, Non-corrosive gas
Pressure port : M5
Connection type : Cable type(cable type cable: 2m)
Pressure type : Standard pressure
Rated pressure range : 0 to 1,000kPa
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Current consumption : Max. 50mA
Protection structure : IP40

Mua Ngay :

Cảm biến áp suất Autonics PSB-C01C-M5

Applicable fluid : (Pneumatic type) Air, Non-corrosive gas
Pressure port : M5
Connection type : Connector type(Connector type cable: 3m)
Pressure type : Compound pressure
Rated pressure range : -100.0 to 100.0kPa
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Current consumption : Max. 50mA
Protection structure : IP40

Mua Ngay :

Cảm biến áp suất Autonics PSB-V01-M5

Applicable fluid : (Pneumatic type) Air, Non-corrosive gas
Pressure port : M5
Connection type : Cable type(cable type cable: 2m)
Pressure type : Negative pressure
Rated pressure range : 0.0 to -101.3kPa
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Current consumption : Max. 50mA
Protection structure : IP40

Mua Ngay :

Cảm biến áp suất Autonics PSM4-VD

Display pressure range : Depending on pressure type, pressure unit ( Rated Pressure and Max. Display Pressure Range)
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Power consumption : Max. 3W
Current consumption : Max. 100mA (adds 20mA for RS485 communication.)
Number of input channels : 4 EA
Environment_Ambient temperature : -10 to 50℃, storage: -20 to 60℃
Environment_Ambient humidity : 30 to 85%RH, storage: 30 to 85%RH
Accessories : Bracket

Mua Ngay :

Cảm biến áp suất Autonics PSM4-AR

Display pressure range : Depending on pressure type, pressure unit ( Rated Pressure and Max. Display Pressure Range)
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Power consumption : Max. 3W
Current consumption : Max. 100mA (adds 20mA for RS485 communication.)
Number of input channels : 4 EA
Environment_Ambient temperature : -10 to 50℃, storage: -20 to 60℃
Environment_Ambient humidity : 30 to 85%RH, storage: 30 to 85%RH
Accessories : Bracket

Mua Ngay :

Cảm biến áp suất Autonics PSM4-APD

Display pressure range : Depending on pressure type, pressure unit ( Rated Pressure and Max. Display Pressure Range)
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Power consumption : Max. 3W
Current consumption : Max. 100mA (adds 20mA for RS485 communication.)
Number of input channels : 4 EA
Environment_Ambient temperature : -10 to 50℃, storage: -20 to 60℃
Environment_Ambient humidity : 30 to 85%RH, storage: 30 to 85%RH
Accessories : Bracket

Mua Ngay :

Cảm biến áp suất Autonics PSM8-VPR

Display pressure range : Depending on pressure type, pressure unit ( Rated Pressure and Max. Display Pressure Range)
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Power consumption : Max. 3W
Current consumption : Max. 100mA (adds 20mA for RS485 communication.)
Number of input channels : 8 EA
Environment_Ambient temperature : -10 to 50℃, storage: -20 to 60℃
Environment_Ambient humidity : 30 to 85%RH, storage: 30 to 85%RH
Accessories : Bracket

Mua Ngay :
