Các sản phẩm được gắn thẻ 'Cảm biến quang điện'

Cảm biến quang điện Autonics BM200-DDT

Sensing type : Diffuse reflective type
Sensing distance : 200mm
Sensing target : Opaque, Translucent material, Transparent material
Light source : Infrared LED(940nm)
Response time : Max. 3ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON(option: Dark ON)
Control output : NPN open collector

Mua Ngay :

Cảm biến quang điện Autonics BMS5M-TDT-P

Sensing type : Through-beam type
Sensing distance : 5m
Sensing target : Opaque material of min. Ø10mm
Light source : Infrared LED(940nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by control wire)
Control output : PNP open collector

Mua Ngay :

Cảm biến quang điện Autonics BM3M-TDT1,2

Sensing type : Through-beam type
Sensing distance : 3m
Sensing target : Opaque material of min. Ø8mm
Light source : Infrared LED(940nm)
Response time : Max. 3ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Dark ON
Control output : NPN open collector

Mua Ngay :

Cảm biến quang điện Autonics BM1M-MDT

Sensing type : Retroreflective type
Sensing distance : 1m(MS-2)
Sensing target : Opaque material of min. Ø60mm
Light source : Infrared LED(940nm)
Response time : Max. 3ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Dark ON
Control output : NPN open collector

Mua Ngay :

Cảm biến quang điện Autonics BX5M-MDT-T

Sensing type : Retroreflective type(standard type)
Sensing distance : 5m(MS-2)
Sensing target : Opaque material of min. Ø60mm
Light source : Infrared LED(850nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : NPN, PNP open collector simultaneous output

Mua Ngay :

Cảm biến quang điện Autonics BX3M-PFR-T

Sensing type : Retroreflective type(built-in polarizing filter)
Sensing distance : 3m
Sensing target : Opaque material of min. Ø60mm
Light source : Red LED(660nm)
Response time : Max. 20ms
Power supply : 24-240VAC~ ±10% 50/60Hz, 24-240VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : Relay

Mua Ngay :

Cảm biến quang điện Autonics BX700-DFR

Sensing type : Diffuse reflective type
Sensing distance : 700mm
Sensing target : Opaque, Translucent material
Light source : Infrared LED(940nm)
Response time : Max. 20ms
Power supply : 24-240VAC~ ±10% 50/60Hz, 24-240VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : Relay

Mua Ngay :

Cảm biến quang điện Autonics BX15M-TDT

Sensing type : Through-beam type
Sensing distance : 15m
Sensing target : Opaque material of min. Ø15mm
Light source : Infrared LED(850nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : NPN, PNP open collector simultaneous output

Mua Ngay :

Cảm biến quang điện Autonics BX5M-MDT

Sensing type : Retroreflective type(standard type)
Sensing distance : 5m(MS-2)
Sensing target : Opaque material of min. Ø60mm
Light source : Infrared LED(850nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : NPN, PNP open collector simultaneous output

Mua Ngay :
