Các sản phẩm được gắn thẻ 'Cảm biến quang điện'

Cảm biến quang điện Autonics BTS1M-TDTD-P
Sensing type : Through-beam type
Sensing distance : 1m
Sensing target : Opaque material of min. Ø2mm
Light source : Red LED(650nm)
Response time : Max. 1ms

Mua Ngay :

Cảm biến quang điện Autonics BTF30-DDTD-P
Sensing type : Diffuse reflective type
Sensing distance : 5 to 30mm
Sensing target : Opaque, Translucent material(min. sensing target: Ø0.2mm)
Light source : Red LED(650nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Dark ON
Control output : PNP open collector

Mua Ngay :

Cảm biến quang điện Autonics BTS200-MDTL-P
Sensing type : Retroreflective type
Sensing distance : 10~200mm
Sensing target : Opaque material of min. Ø27mm(min. sensing target: opaque material of Ø2mm)
Light source : Red LED(650nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON
Control output : PNP open collector

Mua Ngay :

Cảm biến quang điện Autonics BTS200-MDTD-P
Sensing type : Retroreflective type
Sensing distance : 10~200mm
Sensing target : Opaque material of min. Ø27mm(min. sensing target: opaque material of Ø2mm)
Light source : Red LED(650nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Dark ON
Control output : PNP open collector

Mua Ngay :

Cảm biến quang điện Autonics BTF15-BDTL-P
Sensing type : BGS reflective type
Sensing distance : 1 to 15mm
Sensing target : Opaque, Translucent material(min. sensing target: non-illuminated objects of Ø0.2mm)
Light source : Red LED(650nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON
Control output : PNP open collector

Mua Ngay :

Cảm biến quang điện Autonics BTF15-BDTD-P
Sensing type : BGS reflective type
Sensing distance : 1 to 15mm
Sensing target : Opaque, Translucent material(min. sensing target: non-illuminated objects of Ø0.2mm)
Light source : Red LED(650nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Dark ON
Control output : PNP open collector

Mua Ngay :

Cảm biến quang điện Autonics BUP-50-E
Sensing type : Through-beam type
Sensing Channel : 1-channel
Sensing distance : 50mm
Sensing target : Opaquematerial of min. Ø4mm
Light source : Infrared LED(940nm)
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by control wire)
Control output : NPN open collector

Mua Ngay :

Cảm biến quang điện Autonics BUP-30-E
Sensing type : Through-beam type
Sensing Channel : 1-channel
Sensing distance : 30mm
Sensing target : Opaquematerial of min. Ø4mm
Light source : Infrared LED(940nm)
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by control wire)
Control output : NPN open collector

Mua Ngay :

Cảm biến quang điện Autonics BX3M-PDT-T
Sensing type : Retroreflective type(built-in polarizing filter)
Sensing distance : 3m
Sensing target : Opaque material of min. Ø60mm
Light source : Red LED(660nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : NPN, PNP open collector simultaneous output

Mua Ngay :
