Động Cơ Bước 5 Phase Autonics A4K-S564-B
Basic Step Angle [FULL/HALF] : 0.72º/0.36º
Max. holding torque : 4.2kgf.cm
Rotor Moment Of Inertia : 175g·cm²
Winding Resistance : 2.6Ω
Rated current : 0.75A/Phase
Wire connection : Pentagon
Protection structure : IP30
Mua Ngay :
Động Cơ Bước 5 Phase Autonics A8K-S566
Basic Step Angle [FULL/HALF] : 0.72º/0.36º
Max. holding torque : 8.3kgf.cm
Rotor Moment Of Inertia : 280g·cm²
Winding Resistance : 4Ω
Rated current : 0.75A/Phase
Wire connection : Pentagon
Protection structure : IP30
Mua Ngay :
Động Cơ Bước 5 Phase Autonics A4K-M564-B
Basic Step Angle [FULL/HALF] : 0.72º/0.36º
Max. holding torque : 4.2kgf.cm
Rotor Moment Of Inertia : 175g·cm²
Winding Resistance : 0.8Ω
Rated current : 1.4A/Phase
Wire connection : Pentagon
Protection structure : IP30
Mua Ngay :
Động Cơ Bước 5 Phase Autonics A4K-M564
Basic Step Angle [FULL/HALF] : 0.72º/0.36º
Max. holding torque : 4.2kgf.cm
Rotor Moment Of Inertia : 175g·cm²
Winding Resistance : 0.8Ω
Rated current : 1.4
Wire connection : Pentagon
Protection structure : IP30
Mua Ngay :
Động Cơ Bước 5 Phase Autonics A8K-M566
Basic Step Angle [FULL/HALF] : 0.72º/0.36º
Max. holding torque : 8.3kgf.cm
Rotor Moment Of Inertia : 280g·cm²
Winding Resistance : 1.1Ω
Rated current : 1.4A/Phase
Wire connection : Pentagon
Protection structure : IP30
Mua Ngay :
Động Cơ Bước 5 Phase Autonics A8K-M566-B
Basic Step Angle [FULL/HALF] : 0.72º/0.36º
Max. holding torque : 8.3kgf.cm
Rotor Moment Of Inertia : 280g·cm²
Winding Resistance : 1.1Ω
Rated current : 1.4A/Phase
Wire connection : Pentagon
Protection structure : IP30
Mua Ngay :
Động Cơ Bước 5 Phase Autonics AH4K-M564
Basic Step Angle [FULL/HALF] : 0.72º/0.36º
Max. holding torque : 4.2kgf.cm
Rotor Moment Of Inertia : 175g·cm²
Winding Resistance : 0.8Ω
Rated current : 1.4A/Phase
Wire connection : Pentagon
Protection structure : IP30
Mua Ngay :
Động Cơ Bước 5 Phase Autonics A35K-M566-G5
Basic Step Angle [FULL/HALF] : 0.144º/0.072º
Max. allowable torque : 35kgf.cm
Rotor Moment Of Inertia : 280g·cm²
Winding Resistance : 1.1Ω
Rated current : 1.4A/Phase
Wire connection : Pentagon
Protection structure : IP30
Mua Ngay :
Động Cơ Bước 5 Phase Autonics A21K-M596-B
Basic Step Angle [FULL/HALF] : 0.72º/0.36º
Max. holding torque : 21kgf.cm
Rotor Moment Of Inertia : 1400g·cm²
Winding Resistance : 1.76Ω
Rated current : 1.4A/Phase
Wire connection : Pentagon
Protection structure : IP30
Mua Ngay :
