Fail-safe sensor IFM GM505S Fail-safe sensor IFM GM505S SKU: GM505S Hãng sản xuất: IFM Chất lượng: Mới 100% Bảo hành: Chính hãng Chứng từ: CO/CQ, hóa đơn VAT Mua Ngay : nhà chế tạo: IFM SKU: GM505S 1.000 ₫ Số lượng: Thêm vào giỏ hàng Danh sách yêu thích tùy chỉnh được Thêm vào danh sách yêu thích Thêm vào danh sách so sánh Gửi email cho một người bạn Fail-safe sensor IFM GM505SThông Tin Chi Tiết Sản Phẩm Product characteristics Output function clock signal Enable zone [mm] 10…20 Housing rectangular Dimensions [mm] 40 x 40 x 66 Application Special feature Gold-plated contacts Type of operation continuous operation (maintenance-free) Application industrial application Electrical data Operating voltage [V] 19.2…30 DC Rated insulation voltage [V] 30 Current consumption [mA] < 15 Protection class III Reverse polarity protection yes Max. power-on delay time [ms] 5000 Inputs Max. input capacitance Ci_max [nF] 2 Outputs Output function clock signal Output data Interface type B Short-circuit protection yes Max. capacitive load CL_max [nF] 20 Detection zone Enable zone [mm] 10…20 Safe switching-off distance s(ar) [mm] 35 Response times Response time to safety request [ms] 20 Response time when approaching the enable zone [ms] 200; (typical 100) Operating conditions Applications class C to EN 60654-1 weatherproof application Ambient temperature [°C] -25…70 Note on ambient temperature operational life ≤ 87600 h Ambient temperature [°C] 10…40 Note on ambient temperature operational life ≤ 175200 h Rate of temperature change [K/min] 0.5 Max. relative air humidity [%] briefly: 5…95 %; permanent: 5…70 % Air pressure [kPa] 80…106 Ionising radiation not permissible Salt spray no Protection IP 65; IP 67; (to EN 60529) Safety classification ISO 13849-1 category 3, PL e IEC 61508 SIL 3 Mission time TM [h] ≤ 175200 Mission time TM (additional indication) 20 years Safety-related reliability PFHD [1/h] 1E-08 Mechanical data Weight [g] 358 Housing rectangular Mounting non-flush mountable Dimensions [mm] 40 x 40 x 66 Materials PPE; diecast zinc Displays / operating elements Display operation 1 x LED, green signal 1 x LED, yellow Remarks Remarks Unless stated otherwise, all data refer to the reference target plate to IEC 60947-5-2 over the whole temperature range. (FE360 = ST37K) 60x60x1 mm Pack quantity 1 pcs. Electrical connection – plug Connection Connector: 1 x M12; Contacts: gold-plated>Sản Phẩm Liên Quan operational life ≤ 87600 h Thẻ sản phẩm IFM (534) , Fail-safe sensor (14)
