Các sản phẩm được gắn thẻ 'Leadshine'

Closed Loop Stepper Drives EtherCAT Leadshine 2CS3E-D503
No loss of step, no hunting, no torque reservation Dual-axis control via one IP address, support CiA402 EtherCAT communication Support operation modes: Profile Position, Profile Velocity, Homing 2*4 configurable digital inputs, 2*2 optically isolated digital outputs include brake output Low noise and vibration, smooth motion USB port for Leadshine software connection Two 7-segment display velocity or slave ID or operation mode or error code Over voltage, over current and position following error, encoder cable error, etc. protections STO optional

Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025

Mua Ngay :

Closed Loop Stepper Drives Modbus RTU Leadshine CS2RS-D1008
CS2RS Series are closed loop stepper drive based on standard Modbus RTU protocol, using RS485 communication can network up to 31 axes, built-in PR feature with 16-segment position table (PR Mode). They can not only solve the problem of step loss in the open loop stepper system, but also can save additional controllers in most of point-to-point applications, to greatly enhance system reliability and reduce the cost. CS2RS Series also support the feature of teaching, the operation modes of Profile Position, Profile Velocity and Homing. CS2RS-D1008 can power 2-phase NEMA 34 stepper motors with 1000 ppr to 5000 ppr incremental encoders.

Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025

Mua Ngay :

Closed Loop Stepper Drives Modbus RTU Leadshine CS2RS-D507
CS2RS Series are closed loop stepper drive based on standard Modbus RTU protocol, using RS485 communication can network up to 31 axes, built-in PR feature with 16-segment position table (PR Mode). They can not only solve the problem of step loss in the open loop stepper system, but also can save additional controllers in most of point-to-point applications, to greatly enhance system reliability and reduce the cost. CS2RS Series also support the feature of teaching, the operation modes of Profile Position, Profile Velocity and Homing. CS2RS-D503 can power 2-phase NEMA 17, 23, 24 stepper motors with 1000 ppr to 5000 ppr incremental encoders.

Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025

Mua Ngay :

Closed Loop Stepper Drives Modbus RTU Leadshine CS2RS-D503
CS2RS Series are closed loop stepper drive based on standard Modbus RTU protocol, using RS485 communication can network up to 31 axes, built-in PR feature with 16-segment position table (PR Mode). They can not only solve the problem of step loss in the open loop stepper system, but also can save additional controllers in most of point-to-point applications, to greatly enhance system reliability and reduce the cost. CS2RS Series also support the feature of teaching, the operation modes of Profile Position, Profile Velocity and Homing. CS2RS-D503 can power 2-phase NEMA 8, 11, 14, 17 stepper motors with 1000 ppr to 5000 ppr incremental encoders.

Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025

Mua Ngay :

Closed Loop Stepper Drives CS Series Leadshine CS-D507E
The CS series consists of ES seasy servo drives adopting Leadshine latest advanced closed loop control technology. Those drives are highly reliable with good performance and highly competitive cost. They can power a wide range of closed loop stepper motors from NEMA 8 to NEMA 34 (model dependent) with incremental encoders. CS series drives are easy to configure and setup.

Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025

Mua Ngay :

Closed Loop Stepper Motors CS-M Series Leadshine CS-M22323
2 phase, NEMA 23 frame size 96 mm (3.78 inch) long 5 A phase current 2.3 N.m (326 oz-in) holding torque 8 mm (0.315 inch) shaft size Integrated 1,000 line (4,000 count/revolution) quadrature rotary encoder High precision, low motor heating, and low vibration

Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025

Mua Ngay :
