Closed Loop Stepper Drives
Modbus RTU
Leadshine CS2RS-D503
CS2RS Series are closed loop stepper drive based on standard Modbus RTU protocol, using RS485 communication can network up to 31 axes, built-in PR feature with 16-segment position table (PR Mode). They can not only solve the problem of step loss in the open loop stepper system, but also can save additional controllers in most of point-to-point applications, to greatly enhance system reliability and reduce the cost. CS2RS Series also support the feature of teaching, the operation modes of Profile Position, Profile Velocity and Homing. CS2RS-D503 can power 2-phase NEMA 8, 11, 14, 17 stepper motors with 1000 ppr to 5000 ppr incremental encoders.
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Closed Loop Stepper Drives
CS Series
Leadshine CS-D507E
The CS series consists of ES seasy servo drives adopting Leadshine latest advanced closed loop control technology. Those drives are highly reliable with good performance and highly competitive cost. They can power a wide range of closed loop stepper motors from NEMA 8 to NEMA 34 (model dependent) with incremental encoders. CS series drives are easy to configure and setup.
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Closed Loop Stepper Motors
CS-M Series
Leadshine CS-M22323
2 phase, NEMA 23 frame size
96 mm (3.78 inch) long
5 A phase current
2.3 N.m (326 oz-in) holding torque
8 mm (0.315 inch) shaft size
Integrated 1,000 line (4,000 count/revolution) quadrature rotary encoder
High precision, low motor heating, and low vibration
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Closed Loop Stepper Motors
CS-M Series
Leadshine CS-M22430
2 phase, NEMA 24 (60mm) frame size
107 mm (4.21 inch) long
5 A phase current
3 N.m (425 oz-in) holding torque
8 mm (0.315 inch) shaft size
Integrated 1,000 line (4,000 count/revolution) quadrature rotary encoder
High precision, low motor heating, and low vibration
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Closed Loop Stepper Motors
CS-M Series
Leadshine CS-M22331-L
2 phase, NEMA 23 frame size
105 mm (4.13 inch) long
5 A phase current
3.1 N.m (439 oz-in) holding torque
8 mm (0.315 inch) shaft size
Integrated 1,000 line (4,000 count/revolution) quadrature rotary encoder
High precision, low motor heating, and low vibration
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Closed Loop Stepper Motors
CS-M Series
Leadshine CS-M22326
2 phase, NEMA 23 frame size
104 mm (4.09 inch) long
5 A phase current
2.6 N.m (369 oz-in) holding torque
8 mm (0.315 inch) shaft size
Integrated 1,000 line (4,000 count/revolution) quadrature rotary encoder
High precision, low motor heating, and low vibration
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Closed Loop Stepper Motors
CS-M Series
Leadshine CS-M22313
2 phase, NEMA 23 frame size
75 mm (2.95 inch) long
4 A phase current
1.3 N.m (185 oz-in) holding torque
8 mm (0.315 inch) shaft size
Integrated 1,000 line (4,000 count/revolution) quadrature rotary encoder
High precision, low motor heating, and low vibration
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Closed Loop Stepper Motors
CS-M Series
Leadshine CS-M21708
2 phase, NEMA 17 frame size
83 mm (3.27 inch) long
2.5 A phase current
0.8 N.m (114 oz-in) holding torque
5 mm (0.197 inch) shaft size
Integrated 1,000 line (4,000 count/revolution) quadrature rotary encoder
High precision, low motor heating, and low vibration
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Closed Loop Stepper Motors
CS-M Series
Leadshine CS-M21706
2 phase, NEMA 17 frame size
70 mm (2.76 inch) long
2.5 A phase current
0.6 N.m (85 oz-in) holding torque
5 mm (0.197 inch) shaft size
Integrated 1,000 line (4,000 count/revolution) quadrature rotary encoder
High precision, low motor heating, and low vibration
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
