aut.vn Đồng hồ nhiệt Omron E5CS-R1PU-W

Shape : DIN48 x 48
Terminal type : Plug-in
Input type : Platinum resistance thermometer
Control output 1 : Relay output
Control output 2 : None
Number of alarm output : 1 point
Power supply voltage : 100 to 240 VAC (50/60 Hz)
Shape : DIN48 x 48
Fixed/Programmable : Fixed
Power supply voltage : 100 to 240 VAC (50/60 Hz)
Allowable voltage variable range : 85 to 110% of the power supply voltage
Power consumption : 5 VA
Input : Number of input points : 1 point
Temperature input : Platinum resistance thermometer: Pt100, JPt100
Control method : ON/OFF or 2-PID control with auto-tuning
Control output : Number of total control output : 1 point
Control output 1 : Relay output
Control output 2 : None
Relay output : 1 point
SPDT, 250 VAC, 3 A (resistive load)
Alarm output : 1 point1 A at 250 VAC (resistive load)
Setting method : Digital setting using front panel keys
Indication method : 7-segment digital display and deviation indicators
Sampling period : 500 ms
Hysteresis : 0.2% FS (for ON/OFF control)
Proportional band : 1 to 999 ℃ (automatic adjustment using auto-tuning/self-tuning)
Integral time : 1 to 1999 s (automatic adjustment using auto-tuning/self-tuning)
Derivative time : 1 to 1999 s (automatic adjustment using auto-tuning/self-tuning)
Control period : 2 s or 20 s (switchable)
Insulation resistance : 20 MΩ min. (500 VDC megger)
Dielectric strength : 2,000 VAC 50/60 Hz 1 min (Between current-carrying terminals of different polarity)
Vibration resistance : Destruction: 10 to 55 Hz, 0.75 mm for 2 h each in X, Y, and Z directions
Malfunction: 10 to 55 Hz, 20 m/s2 for 10 min each in X, Y, and Z directions
Shock resistance : Destruction: 300 m/s2, 3 times each in 6 directions
Malfunction: 100 m/s2, 3 times each in 6 directions
Ambient temperature (Operating) : -10 to 55 ℃ (with no freezing or condensation)
For 3-year warranty: -10 to 50 ℃
Ambient temperature (Storage) : -25 to 65 ℃ (with no freezing or condensation)
Ambient humidity (Operating) : 25 to 85 %
Degree of protection : Front panel: IP50, Rear case: IP20, Terminal section: IP00
Memory protection : Non-volatile memory (number of writes: 1,000,000)
Case color : Light gray
Terminal type : Plug-in
Accessories : Adapter for Flush Mounting
Weight : Approx. 110 g
Sold separately : Front-connecting Socket (11 Pins): P2CF-11
Front-connecting Socket with Finger Protection (11 Pins): P2CF-11-E
Back Connecting Socket (11 Pins): P3GA-11
Hard Front Cover: Y92A-48B
Protective Cover for finger protection: Y92A-48G
Indication accuracy : Platinum resistance thermometer: (±0.5% of indicated value or ±1 ℃, whichever is greater) ±1 digit max.
(Input set values 1 is 1% FS ±1 digit max.)
Influence of temperature/voltage : Platinum resistance thermometer: (±1% PV or ±2 ℃, whichever is greater) ±1 digit max.
Influence of EMS. : Platinum resistance thermometer: (±1% PV or ±2 ℃, whichever is greater) ±1 digit max.
