AUT.VN REMOTE I/O Autonics ARD-DI08AE
Network : DeviceNet
Type : Digital
Number Of I/Os_Input : 8-point (AC voltage)
I/O specification : Voltage: 75-250VAC~
Current: 13mA/point
Module type : Expansion unit
Power supply : 24VDC @(=)
Protection structure : IP20

Mua Ngay :

aut.vn REMOTE I/O Autonics ARD-DI08A

Network : DeviceNet
Type : Digital
Number Of I/Os_Input : 8-point (AC voltage)
I/O specification : Voltage: 75-250VAC~
Current: 13mA/point
Module type : Basic unit
Power supply : 24VDC @(=)
Protection structure : IP20

Mua Ngay :

AUT.VN REMOTE I/O Autonics ARD-AO04
Network : DeviceNet
Type : Analog
Number Of I/Os_Output : 4-CH(DC voltage 2-CH, DC current 2-CH)
I/O specification : Voltage: 0-10VDC @(=), -10-10VDC @(=), 0-5VDC @(=), 1-5VDC @(=), -5-5VDC @(=)(load resistance: max. 1kΩ)
Current: DC4-20mA, DC0-20mA(load resistance: 600Ω)
Module type : Basic unit
Power supply : 24VDC @(=)
Protection structure : IP20

Mua Ngay :

AUT.VN REMOTE I/O Autonics ARD-AI04
Network : DeviceNet
Type : Analog
Number Of I/Os_Input : 4-CH(switchable DC voltage/current)
I/O specification : Voltage: 0-10VDC, -10-10VDC, 0-5VDC, 1-5VDC, -5-5VDC (input impedance: max. 1MΩ)
Current: DC4-20mA, DC0-20mA (input impedance: 250Ω)
Module type : Basic unit
Power supply : 24VDC @(=)
Protection structure : IP20

Mua Ngay :

aut.vn REMOTE I/O Autonics ADIO-PN-MA08AP-ILM

Upper level comm. protocol : ProfiNet
Lower level comm. protocol : IO-Link ver. 1.1 (port class: Class A)
I/O Configuration : Digital Input 8-CH, Digital Input/Output 8-CH
Power supply port : 7/8 inch, 5-Pin
I/O specification : PNP

Mua Ngay :

aut.vn REMOTE I/O Autonics ADIO-PN-MA08AN-ILM

Upper level comm. protocol : ProfiNet
Lower level comm. protocol : IO-Link ver. 1.1 (port class: Class A)
I/O Configuration : Digital Input 8-CH, Digital Input/Output 8-CH
Power supply port : 7/8 inch, 5-Pin
I/O specification : NPN

Mua Ngay :
