Các sản phẩm được gắn thẻ 'Cảm biến áp suất'

Cảm biến áp suất Autonics PSB-1C-M5
Applicable fluid : (Pneumatic type) Air, Non-corrosive gas
Pressure port : M5
Connection type : Connector type(Connector type cable: 3m)
Pressure type : Standard pressure
Rated pressure range : 0 to 1,000kPa
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Current consumption : Max. 50mA
Protection structure : IP40

Mua Ngay :

Cảm biến áp suất Autonics PSB-01CP-M5
Applicable fluid : (Pneumatic type) Air, Non-corrosive gas
Pressure port : M5
Connection type : Connector type(Connector type cable: 3m)
Pressure type : Standard pressure
Rated pressure range : 0.0 to 100.0kPa
Control output_PNP open collector : PNP open collector
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Current consumption : Max. 50mA
Protection structure : IP40

Mua Ngay :

Cảm biến áp suất Autonics PSB-V01CP-M5
Applicable fluid : (Pneumatic type) Air, Non-corrosive gas
Pressure port : M5
Connection type : Connector type(Connector type cable: 3m)
Pressure type : Negative pressure
Rated pressure range : 0.0 to -101.3kPa
Control output_PNP open collector : PNP open collector
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Current consumption : Max. 50mA
Protection structure : IP40

Mua Ngay :

Cảm biến áp suất Autonics PSB-1CP-M5
Applicable fluid : (Pneumatic type) Air, Non-corrosive gas
Pressure port : M5
Connection type : Connector type(Connector type cable: 3m)
Pressure type : Standard pressure
Rated pressure range : 0 to 1,000kPa
Control output_PNP open collector : PNP open collector
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Current consumption : Max. 50mA
Protection structure : IP40

Mua Ngay :

Cảm biến áp suất Autonics PSB-C01CP-M5
Applicable fluid : (Pneumatic type) Air, Non-corrosive gas
Pressure port : M5
Connection type : Connector type(Connector type cable: 3m)
Pressure type : Compound pressure
Rated pressure range : -100.0 to 100.0kPa
Control output_PNP open collector : PNP open collector
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Current consumption : Max. 50mA
Protection structure : IP40

Mua Ngay :

Cảm biến áp suất Autonics PSS-V01V-R1/8
Pressure type : Negative pressure
Rated pressure range : 0.0 to -101.3kPa
Pressure port : R1/8
Material : Front/Rear case: PBT, Pressure port: Nickel plated brass
Unit weight (packaged weight) : ≈ 50 g (≈ 110 g)
Current consumption : Max. 15mA

Mua Ngay :

Cảm biến áp suất Autonics PSS-C01A-R1/8
Pressure type : Compound pressure
Rated pressure range : -101.3 to 100.0kPa
Pressure port : R1/8
Material : Front/Rear case: PBT, Pressure port: Nickel plated brass
Unit weight (packaged weight) : ≈ 50 g (≈ 110 g)

Mua Ngay :

Cảm biến áp suất Autonics PSS-01V-R04
Pressure type : Standard pressure
Rated pressure range : 0.0 to 100.0kPa
Pressure port : Ø4 reducer
Material : Front/Rear case and pressure port: PBT
Unit weight (packaged weight) : ≈ 45 g (≈ 105g)
Current consumption : Max. 15mA

Mua Ngay :

Cảm biến áp suất Autonics PSS-V01V-R04
Pressure type : Negative pressure
Rated pressure range : 0.0 to -101.3kPa
Pressure port : Ø4 reducer
Material : Front/Rear case and pressure port: PBT
Unit weight (packaged weight) : ≈ 45 g (≈ 105g)
Current consumption : Max. 15mA
