Các sản phẩm được gắn thẻ 'Cảm biến áp suất'

Cảm biến áp suất Autonics PSM4-APR
Display pressure range : Depending on pressure type, pressure unit (refer to '▣ Rated Pressure and Max. Display Pressure Range')
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Power consumption : Max. 3W
Current consumption : Max. 100mA (adds 20mA for RS485 communication.)
Number of input channels : 4 EA
Environment_Ambient temperature : -10 to 50℃, storage: -20 to 60℃
Environment_Ambient humidity : 30 to 85%RH, storage: 30 to 85%RH
Accessories : Bracket

Mua Ngay :

Cảm biến áp suất Autonics PSQ-C01C-R1/8
Applicable fluid : (Pneumatic type) Air, Non-corrosive gas
Pressure port direction : Rear fitting
Pressure port : R1/8
Connection type : Connector type(connector type cable: 2m)
Pressure type : Compound pressure
Control output : Select one at parameter setting
NPN open collector output
PNP open collector output
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Current consumption : Max. 50mA
Protection structure : IP40

Mua Ngay :

Cảm biến áp suất Autonics PSQ-C01C-NPT1/8
Applicable fluid : (Pneumatic type) Air, Non-corrosive gas
Pressure port direction : Rear fitting
Pressure port : NPT1/8
Connection type : Connector type(connector type cable: 2m)
Pressure type : Compound pressure
Control output : Select one at parameter setting
NPN open collector output
PNP open collector output
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Current consumption : Max. 50mA
Protection structure : IP40

Mua Ngay :

Cảm biến áp suất Autonics PSQ-C1C-NPT1/8
Applicable fluid : (Pneumatic type) Air, Non-corrosive gas
Pressure port direction : Rear fitting
Pressure port : NPT1/8
Connection type : Connector type(connector type cable: 2m)
Pressure type : Compound pressure
Control output : Select one at parameter setting
NPN open collector output
PNP open collector output
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Current consumption : Max. 50mA
Protection structure : IP40

Mua Ngay :

Cảm biến áp suất Autonics PSQ-BC01U-R1/8
Applicable fluid : (Fluid type) Air, Non-corrosive gas and fluid that will not corrode Stainless steel 316L
Pressure port direction : Rear fitting
Pressure port : R1/8
Connection type : Cable type(cable type cable: 3m)
Pressure type : Compound pressure
Control output : Select one at parameter setting
NPN open collector output
PNP open collector output
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Current consumption : Max. 50mA(current output: Max. 70mA)
Protection structure : IP65

Mua Ngay :

Cảm biến áp suất Autonics PSQ-BC01U-R1/4
Applicable fluid : (Fluid type) Air, Non-corrosive gas and fluid that will not corrode Stainless steel 316L
Pressure port direction : Rear fitting
Pressure port : R1/4
Connection type : Cable type(cable type cable: 3m)
Pressure type : Compound pressure
Control output : Select one at parameter setting
NPN open collector output
PNP open collector output
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Current consumption : Max. 50mA(current output: Max. 70mA)
Protection structure : IP65

Mua Ngay :

Cảm biến áp suất Autonics PSQ-BC1U-R1/4
Applicable fluid : (Fluid type) Air, Non-corrosive gas and fluid that will not corrode Stainless steel 316L
Pressure port direction : Rear fitting
Pressure port : R1/4
Connection type : Cable type(cable type cable: 3m)
Pressure type : Compound pressure
Control output : Select one at parameter setting
NPN open collector output
PNP open collector output
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Current consumption : Max. 50mA(current output: Max. 70mA)
Protection structure : IP65

Mua Ngay :

Cảm biến áp suất Autonics PSQ-BC01U-Rc1/8
Applicable fluid : (Fluid type) Air, Non-corrosive gas and fluid that will not corrode Stainless steel 316L
Pressure port direction : Rear fitting
Pressure port : Rc1/8
Connection type : Cable type(cable type cable: 3m)
Pressure type : Compound pressure
Control output : Select one at parameter setting
NPN open collector output
PNP open collector output
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Current consumption : Max. 50mA(current output: Max. 70mA)
Protection structure : IP65

Mua Ngay :

Cảm biến áp suất Autonics PSQ-BC1U-Rc1/8
Applicable fluid : (Fluid type) Air, Non-corrosive gas and fluid that will not corrode Stainless steel 316L
Pressure port direction : Rear fitting
Pressure port : Rc1/8
Connection type : Cable type(cable type cable: 3m)
Pressure type : Compound pressure
Control output : Select one at parameter setting
NPN open collector output
PNP open collector output
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Current consumption : Max. 50mA(current output: Max. 70mA)
Protection structure : IP65

Mua Ngay :
