Các sản phẩm được gắn thẻ 'Cảm biến quang điện'

Cảm biến quang điện Autonics BTF1M-TDTL-P

Sensing type : Through-beam type
Sensing distance : 1m
Sensing target : Opaque material of min. Ø2mm
Light source : Red LED(650nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON
Control output : PNP open collector

Mua Ngay :

Cảm biến quang điện Autonics BUP-30S

Sensing type : Through-beam type
Sensing Channel : 1-channel
Sensing distance : 30mm
Sensing target : Opaquematerial of min. Ø1.5mm
Light source : Infrared LED(940nm)
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by control wire)
Control output : NPN open collector

Mua Ngay :

Cảm biến quang điện Autonics BUM4-40D-W-4M

Sensing type : Through-beam type
Sensing Channel : 4-channel
Sensing distance : 40mm
Sensing target : Opaquematerial of min. Ø4mm
Light source : Infrared LED(940nm)
Power supply : 18-35VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Dark ON
Control output : NPN open collector(individual 4 outputs)

Mua Ngay :

Cảm biến quang điện Autonics BL13-TDT

Sensing type : Through-beam type
Applicable pipe : Using binding band: Ø6 to 13mm,
Using protection bracket: Ø12.7mm (1/2 inch) transparent pipe in 1mm thickness (FEP (fluoroplastic) or with equivalent transparency)
Standard sensing target : Liquid in a pipe
Light source : Infrared LED(950nm)
Response time : Max. 2ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by button)
Control output : NPN open collector

Mua Ngay :

Cảm biến quang điện Autonics BTS30-LDTD

Sensing type : Convergent reflective type
Sensing distance : 5 to 30mm
Sensing target : Opaque, Translucent material(min. sensing target: Ø0.15mm)
Light source : Red LED(650nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Dark ON
Control output : NPN open collector

Mua Ngay :

Cảm biến quang điện Autonics BTF30-DDTL

Sensing type : Diffuse reflective type
Sensing distance : 5 to 30mm
Sensing target : Opaque, Translucent material(min. sensing target: Ø0.2mm)
Light source : Red LED(650nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON
Control output : NPN open collector

Mua Ngay :

Cảm biến quang điện Autonics BTS1M-TDTL

Sensing type : Through-beam type
Sensing distance : 1m
Sensing target : Opaque material of min. Ø2mm
Light source : Red LED(650nm)
Response time : Max. 1ms

Mua Ngay :

Cảm biến quang điện Autonics BJ1M-DDT

Sensing type : Diffuse reflective type
Sensing distance : 1m
Sensing target : Opaque, Translucent material
Light source : Infrared LED(850nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : NPN open collector

Mua Ngay :

Cảm biến quang điện Autonics BTS1M-TDTL-P

Sensing type : Through-beam type
Sensing distance : 1m
Sensing target : Opaque material of min. Ø2mm
Light source : Red LED(650nm)
Response time : Max. 1ms

Mua Ngay :
