Cảm biến quang điện

Cảm biến quang điện Autonics BTF30-DDTL

Sensing type : Diffuse reflective type
Sensing distance : 5 to 30mm
Sensing target : Opaque, Translucent material(min. sensing target: Ø0.2mm)
Light source : Red LED(650nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON
Control output : NPN open collector

Cảm biến quang điện Autonics BTF30-DDTL-P

Sensing type : Diffuse reflective type
Sensing distance : 5 to 30mm
Sensing target : Opaque, Translucent material(min. sensing target: Ø0.2mm)
Light source : Red LED(650nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON
Control output : PNP open collector

Cảm biến quang điện Autonics BTF30-DDTD

Sensing type : Diffuse reflective type
Sensing distance : 5 to 30mm
Sensing target : Opaque, Translucent material(min. sensing target: Ø0.2mm)
Light source : Red LED(650nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Dark ON
Control output : NPN open collector

Cảm biến quang điện Autonics BTF30-DDTD-P
Sensing type : Diffuse reflective type
Sensing distance : 5 to 30mm
Sensing target : Opaque, Translucent material(min. sensing target: Ø0.2mm)
Light source : Red LED(650nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Dark ON
Control output : PNP open collector

Thông tin mô tả sản phẩm: E3Z-T82-L 2M

Cảm biến quang OMRON E3Z-T82-L 2M OMI thu-phát riêng (bộ phát)

12...24VDC
Thu-phát riêng (bộ phát)
Khoảng cách phát hiện: 30m
PNP
Dark ON, Light ON

Cảm biến quang điện Autonics BUP-30S

Sensing type : Through-beam type
Sensing Channel : 1-channel
Sensing distance : 30mm
Sensing target : Opaquematerial of min. Ø1.5mm
Light source : Infrared LED(940nm)
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by control wire)
Control output : NPN open collector

Cảm biến quang điện Autonics BUP-30S-P

Sensing type : Through-beam type
Sensing Channel : 1-channel
Sensing distance : 30mm
Sensing target : Opaquematerial of min. Ø1.5mm
Light source : Infrared LED(940nm)
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by control wire)
Control output : PNP open collector

Cảm biến quang điện Autonics BUP-30-E
Sensing type : Through-beam type
Sensing Channel : 1-channel
Sensing distance : 30mm
Sensing target : Opaquematerial of min. Ø4mm
Light source : Infrared LED(940nm)
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by control wire)
Control output : NPN open collector

Cảm biến quang điện Autonics BEN300-DFR

Sensing type : Diffuse reflective type
Sensing distance : 300mm
Sensing target : Opaque, Translucent material
Light source : Infrared LED(940nm)
Response time : Max. 20ms
Power supply : 24-240VAC~ ±10% 50/60Hz, 24-240VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : Relay
