Cảm biến sợi quang

Cảm biến sợi quang Autonics BF4RP

Type : Standard type
Light source : Red LED(660nm)
Response time : Frequency 1: Max. 0.5ms, Frequency 2: Max. 0.7ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by ON/OFF button)
Control output : PNP open collector

Mua Ngay :

Cảm biến sợi quang Autonics BF4R-R

Type : External input sensitivity setting type
Light source : Red LED(660nm)
Response time : Frequency 1: Max. 0.5ms, Frequency 2: Max. 0.7ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by ON/OFF button)
Control output : NPN open collector

Mua Ngay :

Cảm biến sợi quang Autonics BF5B-D1-N

Type : Dual display
Display method : 4-digit 7-segment LED
Light source : Blue LED(470nm)
Response time : 50㎲, 150㎲, 500㎲, 4ms, 10ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by parameter)
Control output : NPN open collector

Mua Ngay :

Cảm biến sợi quang Autonics BF5B-D1-P
Type : Dual display
Display method : 4-digit 7-segment LED
Light source : Blue LED(470nm)
Response time : 50㎲, 150㎲, 500㎲, 4ms, 10ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by parameter)
Control output : PNP open collector

Mua Ngay :

Cảm biến sợi quang Autonics BF5G-D1-N

Type : Dual display
Display method : 4-digit 7-segment LED
Light source : Green LED(530nm)
Response time : 50㎲, 150㎲, 500㎲, 4ms, 10ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by parameter)
Control output : NPN open collector

Mua Ngay :

Cảm biến sợi quang Autonics BF5G-D1-P
Type : Dual display
Display method : 4-digit 7-segment LED
Light source : Green LED(530nm)
Response time : 50㎲, 150㎲, 500㎲, 4ms, 10ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by parameter)
Control output : PNP open collector

Mua Ngay :

Cảm biến sợi quang Autonics BF5R-D1-N

Type : Dual display
Display method : 4-digit 7-segment LED
Light source : Red LED(660nm)
Response time : 50㎲, 150㎲, 500㎲, 4ms, 10ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by parameter)
Control output : NPN open collector

Mua Ngay :

Cảm biến sợi quang Autonics BF5R-D1-P

Type : Dual display
Display method : 4-digit 7-segment LED
Light source : Red LED(660nm)
Response time : 50㎲, 150㎲, 500㎲, 4ms, 10ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by parameter)
Control output : PNP open collector

Mua Ngay :

Cảm biến sợi quang Autonics BF5R-S1-N

Type : Single display
Display method : 4-digit 7-segment LED
Light source : Red LED(660nm)
Response time : 150㎲, 500㎲, 4ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by parameter)
Control output : NPN open collector

Mua Ngay :
