Các sản phẩm được gắn thẻ 'Cầu đấu dây'

AUT.VN Cầu đấu dây Autonics ACS-50L
Number of terminal : 50 EA
Terminal pitch : 7.0mm
Material : CASE & BASE: Modified Polyphenylene Oxide, TERMINAL PIN: Brass
Weight : Approx. 189g(approx. 141g)
Rated voltage : ≤125VDC @(=), 125VAC~ 50/60Hz
Rated current : Max. 10A
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃

Mua Ngay :

AUT.VN Cầu đấu dây Autonics ACS-50T
Number of terminal : 50 EA
Terminal pitch : 7.0mm
Material : CASE & BASE: Modified Polyphenylene Oxide, TERMINAL PIN: Brass
Weight : Approx. 189g(approx. 141g)
Rated voltage : ≤125VDC @(=), 125VAC~ 50/60Hz
Rated current : Max. 10A
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃

Mua Ngay :

AUT.VN Cầu đấu dây Autonics AFL-H40
Number of terminal : 40 EA
Terminal type : Screwless
Terminal pitch : 5.0mm
Material : CASE: Polycarbonate, BASE: Polycarbonate
Weight : Approx. 156g(approx. 89g)
Rated voltage : ≤125VDC @(=), 125VAC~ 50/60Hz
Rated current : ≤1A
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃
Protection structure : IP20(IEC standard)

Mua Ngay :

AUT.VN Cầu đấu dây Autonics AFR-H40-LP
Number of terminal : 32 EA
Terminal type : Rising Clamp
Material : CASE: Polycarbonate, BASE: Polycarbonate
Rated voltage : 24VDC @(=) ±10%
Rated current : ≤1A
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃
Protection structure : IP20(IEC standard)

Mua Ngay :

AUT.VN Cầu đấu dây Autonics ABS-S01R25-CN
Rated voltage : 200/220VAC~
Rated load voltage & current : 250VAC~ 10A, 30VDC @(=) 10A
Current consumption : ≤10mA
Applied relay : G2R-1-S200/(220)VAC [OMRON]
Number of relay points : 1-point
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃
Material : CASE, BASE: PBT, TERMINAL PIN: Brass, Phosphor bronze

Mua Ngay :

AUT.VN Cầu đấu dây Autonics ABS-H16PA-PN
Rated voltage : 24VDC @(=) ±10%
Rated load voltage & current : 250VAC~ 3A, 30VDC @(=) 3A
Current consumption : ≤8mA/≤13mA
Applied relay : APAN3124 [MATSUSHITA(Panasonic)]
Number of relay points : 16-point
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃
Material : CASE: MPPO, BASE: Polyamide 66 (G25%), TERMINAL PIN: Brass

Mua Ngay :

AUT.VN Cầu đấu dây Autonics ABS-H16TN-NN
Rated voltage : 24VDC @(=) ±10%
Rated load voltage & current : 250VAC~ 3A, 30VDC @(=) 3A
Current consumption : ≤8.5mA/≤13.5mA
Applied relay : NYP24W-K[TAKAMISAWA(Fujitsu)]
Number of relay points : 16-point
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃
Material : CASE: MPPO, BASE: Polyamide 66 (G25%), TERMINAL PIN: Brass

Mua Ngay :

AUT.VN Cầu đấu dây Autonics ABS-H16TN-PN
Rated voltage : 24VDC @(=) ±10%
Rated load voltage & current : 250VAC~ 3A, 30VDC @(=) 3A
Current consumption : ≤8.5mA/≤13.5mA
Applied relay : NYP24W-K[TAKAMISAWA(Fujitsu)]
Number of relay points : 16-point
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃
Material : CASE: MPPO, BASE: Polyamide 66 (G25%), TERMINAL PIN: Brass

Mua Ngay :

AUT.VN Cầu đấu dây Autonics AFR-H20-LN
Number of terminal : 16 EA
Terminal type : Rising Clamp
Material : CASE: Polycarbonate, BASE: Polycarbonate
Rated voltage : 24VDC @(=) ±10%
Rated current : ≤1A
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃
Protection structure : IP20(IEC standard)

Mua Ngay :
