Cầu đấu dây Autonics AFR-H20-LP
Number of terminal : 16 EA
Terminal type : Rising Clamp
Material : CASE: Polycarbonate, BASE: Polycarbonate
Rated voltage : 24VDC @(=) ±10%
Rated current : ≤1A
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃
Protection structure : IP20(IEC standard)
Cầu đấu dây Autonics ABS-S01TN-CN
Rated voltage : 24VDC @(=) ±10%
Rated load voltage & current : 250VAC~ 3A, 30VDC @(=) 3A
Current consumption : ≤8.5mA
Applied relay : NYP24W-K[TAKAMISAWA(Fujitsu)]
Number of relay points : 1-point
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃
Material : CASE & BASE: PA6, TERMINAL PIN: Brass
Cầu đấu dây Autonics ABS-S04TN-CN
Rated voltage : 24VDC @(=) ±10%
Rated load voltage & current : 250VAC~ 3A, 30VDC @(=) 3A
Current consumption : ≤8.5mA
Applied relay : NYP24W-K[TAKAMISAWA(Fujitsu)]
Number of relay points : 4-point
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃
Material : CASE & BASE: Modified Polyphenylene Oxide, TERMINAL PIN: Brass
Cầu đấu dây Autonics ASL-L04SP0-UN
Rated voltage : 24VDC @(=) ±10%
Rated load voltage & current : 75-240VAC~ 50/60Hz 1A
Current consumption : ≤ 18mA
Applied SSR : AQG12124(Panasonic)
Terminal type : Screwless
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃
Protection structure : IP20(IEC standard)
Cầu đấu dây Autonics ABS-S01PQ-CN
Rated voltage : 24VDC @(=) ±10%
Rated load voltage & current : 250VAC~ 5A, 30VDC @(=) 5A
Current consumption : ≤20mA
Applied relay : PQ1a-24V [MATSUSHITA(Panasonic)]
Number of relay points : 1-point
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃
Material : CASE & BASE: PA6, TERMINAL PIN: Brass
Cầu đấu dây Autonics ACS-B40T
Number of terminal : 40 EA
Terminal pitch : 7.2mm
Material : Case, Base: PC, terminal: brass
Weight : Approx. 149g(approx. 120g)
Rated voltage : ≤125VDC @(=), 125VAC~ 50/60Hz
Rated current : Max. 10A
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃
Cầu đấu dây Autonics ASL-L01SR0-PY
Rated voltage : 24VDC @(=) ±10%
Rated load voltage & current : 24-240VAC~ 50/60Hz 2A
Current consumption : ≤ 18mA
Applied SSR : G3MC-202P(Omron)
Terminal type : Screwless
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃
Protection structure : IP20(IEC standard)
Cầu đấu dây Autonics ABS-S01R6-CN
Rated voltage : 24VDC @(=) ±10%
Rated load voltage & current : 250VAC~ 5A, 30VDC @(=) 5A
Current consumption : ≤20mA
Applied relay : G6B-1174P-FD-US[OMRON]
Number of relay points : 1-point
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃
Material : CASE & BASE: PA6, TERMINAL PIN: Brass
Cầu đấu dây Autonics ASL-L01SR0-NN
Rated voltage : 24VDC @(=) ±10%
Rated load voltage & current : 24-240VAC~ 50/60Hz 2A
Current consumption : ≤ 18mA
Applied SSR : G3MC-202P(Omron)
Terminal type : Screwless
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃
Protection structure : IP20(IEC standard)
