Cảm biến Encoder

Cảm biến Encoder Autonics E58HB12-2000-6-L-5-CS
Shaft inner diameter : Ø12mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 90gf.cm(max. 0.00882N.m)
Resolution : 2000P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial connector type
Protection structure : IP50

Cảm biến Encoder Autonics E58HB12-2048-6-L-5-CS
Shaft inner diameter : Ø12mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 90gf.cm(max. 0.00882N.m)
Resolution : 2048P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial connector type
Protection structure : IP50

Cảm biến Encoder Autonics E58HB12-2500-6-L-5-CS
Shaft inner diameter : Ø12mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 90gf.cm(max. 0.00882N.m)
Resolution : 2500P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial connector type
Protection structure : IP50

Cảm biến Encoder Autonics E58HB12-3000-6-L-5-CS
Shaft inner diameter : Ø12mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 90gf.cm(max. 0.00882N.m)
Resolution : 3000P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial connector type
Protection structure : IP50

Cảm biến Encoder Autonics E58HB12-3600-6-L-5-CS
Shaft inner diameter : Ø12mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 90gf.cm(max. 0.00882N.m)
Resolution : 3600P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial connector type
Protection structure : IP50

Cảm biến Encoder Autonics E58SC10-5000-6-L-5

Đường kính ngoài trục : Ø10mm
Tần số đáp ứng tối đa : 300kHz
Độ phân giải cho phép tối đa : 5000rpm
Mô-men khởi động : Max. 40gf.cm(max. 0.00392N.m)
Độ phân giải : 5000P/R
Ngõ ra điều khiển : Line Driver
Nguồn cấp : 5VDC @(=) ±5%(sóng P-P: max. 5%)
Loại kết nối : Loại cáp trục
Cấu trúc bảo vệ : IP50

Cảm biến Encoder Autonics E58SS6-5000-6-L-5
Shaft outer diameter : Ø6mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 40gf.cm(max. 0.00392N.m)
Resolution : 5000P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type
Protection structure : IP50

Cảm biến Encoder Autonics E58SC10-5000-6-L-24
Shaft outer diameter : Ø10mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 40gf.cm(max. 0.00392N.m)
Resolution : 5000P/R
Control output : Line Driver
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type
Protection structure : IP50

Cảm biến Encoder  Omron E6B2-CWZ1X 600P/R 2M
Rotary Encoder
Incremental
External Diameter: 40 dia.
Line driver output
600 P/R
5 VDC
Phases A/-A/B/-B/Z/-Z
Pre-wired model
2 m
