Cảm biến Encoder

Cảm biến Encoder Autonics E58H12-5000-6-L-5-C
Shaft inner diameter : Ø12mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 90gf.cm(max. 0.00882N.m)
Resolution : 5000P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial cable connector type
Protection structure : IP50

Thông tin mô tả sản phẩm: E6A2-CS5C 20P/R 0.5M

Rotary encoder E6A2-CS5C 20P/R 0.5M Omron
12...24VDC

12...24VDC
Loại trục
20 xung

Thông tin mô tả sản phẩm: E6B2-CWZ3E 2000P/R 2M

Bộ mã hóa vòng quay tương đối OMRON E6B2-CWZ3E 2000P/R 2M

5...12VDC
Loại trục
2000 xung

Cảm biến Encoder  Omron E6B2-CWZ6C 50P/R 2M
Rotary Encoder
Incremental
External Diameter: 40 dia.
NPN open-collector output
50 P/R
5 to 24 VDC
Phases A/B/Z
Pre-wired model
2 m

Cảm biến Encoder Autonics E60H20-5000-3-T-24

Đường kính trong trục : Ø20mm
Tần số đáp ứng tối đa : 300kHz
Độ phân giải cho phép tối đa : 6000rpm
Mô-men khởi động : Max. 150gf.cm(max. 0.0147N.m)
Độ phân giải : 5000P/R
Ngõ ra điều khiển : Totem pole
Nguồn cấp : 12-24VDC @(=) ±5%(sóng P-P: max. 5%)
Loại kết nối : loại cáp hướng tâm
Cấu trúc bảo vệ : IP50

Cảm biến Encoder Autonics E58SC10-6000-6-L-5
Shaft outer diameter : Ø10mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 40gf.cm(max. 0.00392N.m)
Resolution : 6000P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type
Protection structure : IP50

Cảm biến Encoder Autonics E58SS6-6000-6-L-5
Shaft outer diameter : Ø6mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 40gf.cm(max. 0.00392N.m)
Resolution : 6000P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type
Protection structure : IP50

Cảm biến Encoder Autonics E60H20-5000-3-T-5
Shaft inner diameter : Ø20mm
Max. response frequency : 300kHz
Max. allowable revolution : 6000rpm
Starting torque : Max. 150gf.cm(max. 0.0147N.m)
Resolution : 5000P/R
Control output : Totem pole
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial cable type
Protection structure : IP50

Cảm biến Encoder Autonics E60H20-5000-3-N-24
Shaft inner diameter : Ø20mm
Max. response frequency : 300kHz
Max. allowable revolution : 6000rpm
Starting torque : Max. 150gf.cm(max. 0.0147N.m)
Resolution : 5000P/R
Control output : NPN open collector
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial cable type
Protection structure : IP50
