Cảm biến Encoder

Cảm biến Encoder Autonics EPM50S8-1013-B-S-24-S

Đường kính ngoài trục : Ø8mm
Độ phân giải cho phép tối đa : 3000rpm
Mô-men khởi động : Max. 70gf.cm(max. 0.0069N.m)
Độ phân giải : Một vòng: 1024-division, Nhiều vòng: 8192-vòng
Mã ngõ ra : Mã nhị phân
Ngõ ra điều khiển : SSI(Giao diện nối tiếp đồng bộ)
Nguồn cấp : 12-24VDC @(=) ±5%(sóng P-P: max. 5%)
Loại kết nối : loại cáp hướng tâm
Cấu trúc bảo vệ : IP50

Cảm biến Encoder Autonics E80H30-60-6-L-5-C
Shaft inner diameter : Ø30mm
Max. response frequency : 200kHz
Max. allowable revolution : 3600rpm
Starting torque : Max. 200gf.cm(max. 0.0196N.m)
Resolution : 60P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial cable connector type
Protection structure : IP50

Cảm biến Encoder Autonics E80H30-512-6-L-5-C
Shaft inner diameter : Ø30mm
Max. response frequency : 200kHz
Max. allowable revolution : 3600rpm
Starting torque : Max. 200gf.cm(max. 0.0196N.m)
Resolution : 512P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial cable connector type
Protection structure : IP50

Cảm biến Encoder Autonics E80H32-512-6-L-5-C
Shaft inner diameter : Ø32mm
Max. response frequency : 200kHz
Max. allowable revolution : 3600rpm
Starting torque : Max. 200gf.cm(max. 0.0196N.m)
Resolution : 512P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial cable connector type
Protection structure : IP50

Cảm biến Encoder  Omron E6B2-CWZ5B 600P/R 2M
Rotary Encoder
Incremental
External Diameter: 40 dia.
PNP open-collector output
600 P/R
12 to 24 VDC
Phases A/B/Z
Pre-wired model
2 m

Cảm biến Encoder  Omron E6C2-CWZ6C 800P/R 2M
Rotary Encoder
Incremental
External Diameter: 50 dia.
NPN Open-collector output
800 P/R
5 to 24 VDC
Phases A/B/Z
Pre-wired model
2 m

Cảm biến Encoder  Omron E6C2-CWZ6C 2000P/R 2M
Rotary Encoder
Incremental
External Diameter: 50 dia.
NPN Open-collector output
2000 P/R
5 to 24 VDC
Phases A/B/Z
Pre-wired model
2 m

Cảm biến Encoder  Omron E6C2-CWZ3E 800P/R 2M
Rotary Encoder
Incremental
External Diameter: 50 dia.
Voltage output
800 P/R
5 to 12 VDC
Phases A/B/Z
Pre-wired model
2 m

Cảm biến Encoder  Omron E6C2-CWZ5B 100P/R 2M
Rotary Encoder
Incremental
External Diameter: 50 dia.
PNP Open-collector output
100 P/R
12 to 24 VDC
Phases A/B/Z
Pre-wired model
2 m
