Cảm biến Encoder

Cảm biến Encoder Autonics EWLS50-512-B-PN-24
Shaft outer diameter : 50mm×50mm
Max. response frequency : 50kHz
Max. output pulse : 5,120division/512mm(resolution: 0.1mm)
Measurement range : 512mm
Output code : Binary Code
Control output : Parallel NPN open collector
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type

Cảm biến Encoder Autonics EWLS50-512-G-PN-24
Shaft outer diameter : 50mm×50mm
Max. response frequency : 50kHz
Max. output pulse : 5,120division/512mm(resolution: 0.1mm)
Measurement range : 512mm
Output code : Gray Code
Control output : Parallel NPN open collector
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type

Thông tin mô tả sản phẩm: E6A2-CW5C 500P/R 2M

Bộ mã hóa vòng quay tương đối OMRON E6A2-CW5C 500P/R 2M

12...24VDC
Loại trục
500 xung

Cảm biến Encoder Autonics E80H30-1024-3-T-24-C
Shaft inner diameter : Ø30mm
Max. response frequency : 200kHz
Max. allowable revolution : 3600rpm
Starting torque : Max. 200gf.cm(max. 0.0196N.m)
Resolution : 1024P/R
Control output : Totem pole
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial cable connector type
Protection structure : IP50

Cảm biến Encoder Autonics E80H30-3200-3-T-24-C
Shaft inner diameter : Ø30mm
Max. response frequency : 200kHz
Max. allowable revolution : 3600rpm
Starting torque : Max. 200gf.cm(max. 0.0196N.m)
Resolution : 3200P/R
Control output : Totem pole
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial cable connector type
Protection structure : IP50

Cảm biến Encoder Autonics E80H30-3200-3-T-5-C
Shaft inner diameter : Ø30mm
Max. response frequency : 200kHz
Max. allowable revolution : 3600rpm
Starting torque : Max. 200gf.cm(max. 0.0196N.m)
Resolution : 3200P/R
Control output : Totem pole
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial cable connector type
Protection structure : IP50

Cảm biến Encoder Autonics E80H30-1024-3-N-24-C
Shaft inner diameter : Ø30mm
Max. response frequency : 200kHz
Max. allowable revolution : 3600rpm
Starting torque : Max. 200gf.cm(max. 0.0196N.m)
Resolution : 1024P/R
Control output : NPN open collector
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial cable connector type
Protection structure : IP50

Cảm biến Encoder  Omron E6C3-CWZ3EH 2048P/R 1M
Rugged Rotary Encoder
Incremental
External Diameter: 50 dia.
Voltage output (NPN)
2048 P/R
5 to 12 VDC
Phases A/B/Z
Pre-wired model
1 m

Cảm biến Encoder  Omron E6C3-CWZ3EH 2500P/R 1M
Rugged Rotary Encoder
Incremental
External Diameter: 50 dia.
Voltage output (NPN)
2500 P/R
5 to 12 VDC
Phases A/B/Z
Pre-wired model
1 m
