Các sản phẩm được gắn thẻ 'Cảm biến quang điện'

Cảm biến quang điện Autonics BJ300-DDT

Sensing type : Diffuse reflective type
Sensing distance : 300mm
Sensing target : Opaque, Translucent material
Light source : Red LED(660nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : NPN open collector

Mua Ngay :

Cảm biến quang điện Autonics BTS30-LDTD-P

Sensing type : Convergent reflective type
Sensing distance : 5 to 30mm
Sensing target : Opaque, Translucent material(min. sensing target: Ø0.15mm)
Light source : Red LED(650nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Dark ON
Control output : PNP open collector

Mua Ngay :

Cảm biến quang điện Autonics BJ300-DDT-C-P

Sensing type : Diffuse reflective type
Sensing distance : 300mm
Sensing target : Opaque, Translucent material
Light source : Red LED(660nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : PNP open collector

Mua Ngay :

Cảm biến quang điện Autonics BJN50-NDT-P

Sensing type : Narrow beam reflective type
Sensing distance : 30 to 70mm
Sensing target : Opaque, Translucent material(min. sensing target: min. Ø0.2mm(copper wire))
Light source : Red LED(650nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : PNP open collector

Mua Ngay :

Cảm biến quang điện Autonics BTF15-BDTD

Sensing type : BGS reflective type
Sensing distance : 1 to 15mm
Sensing target : Opaque, Translucent material(min. sensing target: non-illuminated objects of Ø0.2mm)
Light source : Red LED(650nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Dark ON
Control output : NPN open collector

Mua Ngay :

Cảm biến quang điện Autonics BJ3M-PDT

Sensing type : Retroreflective type(built-in polarizing filter)
Sensing distance : 3m(MS-2A)
Sensing target : Opaque material of min. Ø75mm
Light source : Red LED(660nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : NPN open collector

Mua Ngay :

Cảm biến quang điện Autonics BJG30-DDT

Sensing type : Diffuse reflective type
Sensing distance : 30mm(Non-glossy white paper 100×100mm), 15mm(Transparent glass 50×50mm, t=3.0mm)
Sensing target : Opaque, Translucent material(30mm), Transparent glass(15mm)
Light source : Infrared LED(850nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON
Control output : NPN open collector

Mua Ngay :

Cảm biến quang điện Autonics BJ3M-PDT-C-P

Sensing type : Retroreflective type(built-in polarizing filter)
Sensing distance : 3m(MS-2A)
Sensing target : Opaque material of min. Ø75mm
Light source : Red LED(660nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : PNP open collector

Mua Ngay :

Cảm biến quang điện Autonics BJN100-NDT

Sensing type : Narrow beam reflective type
Sensing distance : 70 to 130mm
Sensing target : Opaque, Translucent material(min. sensing target: min. Ø0.2mm(copper wire))
Light source : Red LED(650nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : NPN open collector

Mua Ngay :
