Các sản phẩm được gắn thẻ 'Cảm biến quang điện'

Cảm biến quang điện Autonics BJ50-BDT

Sensing type : BGS reflective type
Sensing distance : 10 to 50mm
Sensing target : Opaque, Translucent material
Light source : Red LED(660nm)
Response time : Max. 1.5ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : NPN open collector

Mua Ngay :

Cảm biến quang điện Autonics BJN100-NDT-P

Sensing type : Narrow beam reflective type
Sensing distance : 70 to 130mm
Sensing target : Opaque, Translucent material(min. sensing target: min. Ø0.2mm(copper wire))
Light source : Red LED(650nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : PNP open collector

Mua Ngay :

Cảm biến quang điện Autonics BJN50-NDT

Sensing type : Narrow beam reflective type
Sensing distance : 30 to 70mm
Sensing target : Opaque, Translucent material(min. sensing target: min. Ø0.2mm(copper wire))
Light source : Red LED(650nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : NPN open collector

Mua Ngay :

Cảm biến quang điện Autonics BUP-50S

Sensing type : Through-beam type
Sensing Channel : 1-channel
Sensing distance : 50mm
Sensing target : Opaquematerial of min. Ø1.5mm
Light source : Infrared LED(940nm)
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by control wire)
Control output : NPN open collector

Mua Ngay :

Cảm biến quang điện Autonics BTF1M-TDTL

Sensing type : Through-beam type
Sensing distance : 1m
Sensing target : Opaque material of min. Ø2mm
Light source : Red LED(650nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON
Control output : NPN open collector

Mua Ngay :

Cảm biến quang điện Autonics BUP-50S-P

Sensing type : Through-beam type
Sensing Channel : 1-channel
Sensing distance : 50mm
Sensing target : Opaquematerial of min. Ø1.5mm
Light source : Infrared LED(940nm)
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by control wire)
Control output : PNP open collector

Mua Ngay :

Cảm biến quang điện Autonics BUP-30

Sensing type : Through-beam type
Sensing Channel : 1-channel
Sensing distance : 30mm
Sensing target : Opaquematerial of min. Ø4mm
Light source : Infrared LED(940nm)
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by control wire)
Control output : NPN open collector

Mua Ngay :

Cảm biến quang điện Autonics BJ100-DDT-P

Sensing type : Diffuse reflective type
Sensing distance : 100mm
Sensing target : Opaque, Translucent material
Light source : Infrared LED(850nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : PNP open collector

Mua Ngay :

Cảm biến quang điện Autonics BH4M-PDT

Sensing type : Retroreflective type(built-in polarizing filter)
Sensing distance : 4m(MS-2A)
Sensing target : Opaque material of min. Ø75mm
Light source : Red LED(660nm)
Response time : Max. 1ms

Mua Ngay :
