Các sản phẩm được gắn thẻ 'Cảm biến quang điện'

Cảm biến quang điện Autonics BH20M-TDT

Sensing type : Through-beam type
Sensing distance : 20m
Sensing target : Opaque material of min. Ø20mm
Light source : Red LED(660nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : NPN, PNP open collector simultaneous output

Mua Ngay :

Cảm biến quang điện Autonics BJ10M-TDT-P

Sensing type : Through-beam type
Sensing distance : 10m
Sensing target : Opaque material of min. Ø12mm
Light source : Red LED(660nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : PNP open collector

Mua Ngay :

Cảm biến quang điện Autonics BJ100-DDT-C

Sensing type : Diffuse reflective type
Sensing distance : 100mm
Sensing target : Opaque, Translucent material
Light source : Infrared LED(850nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : NPN open collector

Mua Ngay :

Cảm biến quang điện Autonics BJ15M-TDT

Sensing type : Through-beam type
Sensing distance : 15m
Sensing target : Opaque material of min. Ø12mm
Light source : Infrared LED(850nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : NPN open collector

Mua Ngay :

Cảm biến quang điện Autonics BJ10M-TDT-C

Sensing type : Through-beam type
Sensing distance : 10m
Sensing target : Opaque material of min. Ø12mm
Light source : Red LED(660nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : NPN open collector

Mua Ngay :

Cảm biến quang điện Autonics BJ15M-TDT-P

Sensing type : Through-beam type
Sensing distance : 15m
Sensing target : Opaque material of min. Ø12mm
Light source : Infrared LED(850nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : PNP open collector

Mua Ngay :

Cảm biến quang điện Autonics BH300-DDT

Sensing type : Diffuse reflective type
Sensing distance : 300mm
Light source : Red LED(660nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : NPN, PNP open collector simultaneous output

Mua Ngay :

Cảm biến quang điện Autonics BEN300-DFR

Sensing type : Diffuse reflective type
Sensing distance : 300mm
Sensing target : Opaque, Translucent material
Light source : Infrared LED(940nm)
Response time : Max. 20ms
Power supply : 24-240VAC~ ±10% 50/60Hz, 24-240VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : Relay

Mua Ngay :

Cảm biến quang điện Autonics BJ100-DDT

Sensing type : Diffuse reflective type
Sensing distance : 100mm
Sensing target : Opaque, Translucent material
Light source : Infrared LED(850nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : NPN open collector

Mua Ngay :
