Timer Omron H3CA-8 AC200/220/240

Timer Omron H3CA-8 AC200/220/240
Solid-state Timer
Power ON-delay
Time-limit contact DPDT
Time range: 0.1 s to 9990 h
8-pin
Flush or Surface mounting
200/220/240 VAC

Mua Ngay : Zalo

nhà chế tạo: Omron
SKU: H3CA-8 AC200/220/240
Ngày giao hàng: 1-3 days
Giá cũ: 2.094.919 ₫
1.745.766 ₫
Giao đến
*
*
Phương pháp vận chuyển
Tên
Ngày dự kiến giao hàng
Giá bán
Không có tùy chọn giao hàng nào

Thông Tin Sản Phẩm: H3CA-8 AC200/220/240

Thông Tin Kỹ Thuật cơ bản của : Timer Omron H3CA-8 DC100

Rated supply voltage 200/220/240 VAC
Time range 0.1 s to 9990 h
Input method No-voltage input (open and short-circuit)
Control output Time-limit contact: DPDT
Display method LCD 3 digit
External connection method 8-pin round socket

Thông số kỹ thuật chi tiết sản phẩm: Timer Omron H3CA-8 DC100

Rated supply voltage200/220/240 VAC (50/60 Hz)
Operating voltage range85 to 110% of rated supply voltage
Power consumptionApprox. 10 VA/Approx. 1 W
Time ranges(Number of ranges)7
Time ranges0.1 to 99.9 s1 to 999 s0.1 to 99.9 min1 to 999 min0.1 to 99.9 h1 to 999 h10 to 9990 h
Input methodNo-voltage input (open and short-circuit)
Output modesA: Power ON delay
Control output (Contact output)Time-limit contact: DPDTResistive load: 3 A at 250 VACMinimum applicable load: 10 mA at 5 VDC (failure level: P Reference value)
Reset systemSelf-reset
Power resetReset time: 0.1 s max.
Display methodLCD 3 digit
Ambient temperature (Operating)-10 to 55 ℃ (with no icing)
Ambient humidity (Operating)35 to 85 %
Accuracy of operating time±0.3% ±0.05 s (The values are based on the set value.)
Setting error±0.5% ±0.05 s (The values are based on the set value.)
Influence of voltage±0.3% ±0.05 s (The values are based on the set value.)
Influence of temperature±0.3% ±0.05 s (The values are based on the set value.)
Insulation resistance100 MΩ min. (at 500 VDC)
Dielectric strengthBetween current carrying metal parts and non-current carrying metal parts: 2000 VAC 50/60 Hz 1 minBetween control output terminals and operating circuit: 2000 VAC 50/60 Hz 1 minBetween non-continuous contacts: 1000 VAC 50/60 Hz 1 min
Impulse withstand voltageBetween power terminals: 5 kVBetween current carrying terminals and exposed non-current carrying metal parts: 5 kV
Vibration resistanceDestruction: 10 to 55 Hz, 0.75 mm single amplitude each in 3 directions for 1 hourMalfunction: 10 to 55 Hz, 0.5 mm single amplitude each in 3 directions for 10 min
Shock resistanceDestruction: 1,000 m/s2, 3 times each in 6 directionsMalfunction: 100 m/s2, 3 times each in 6 directions
Life expectancyElectrical: 100,000 operations min. (3 A at 250 VAC resistive load at 1800 operations/h)Mechanical: 10 million operations min. (under no load at 1,800 operations/h)
Degree of protectionIP40
Mounting methodFlush mounting / Surface mounting
External connection method8-pin round socket
Applicable socketP2CF-08, P2CF-08-E, P3G-08, PL08
Accessory (sold separately)Soft Cover: Y92A-48DHard Cover: Y92A-48BFlush mounting adapter: Y92F-30/Y92F-70/Y92F-71
