Timer Omron H3CA-8 DC24 Timer Omron H3CA-8 DC24 Solid-state Timer Power ON-delay Time-limit contact DPDT Time range: 0.1 s to 9990 h 8-pin Flush or Surface mounting 24 VDC Mua Ngay : nhà chế tạo: Omron SKU: H3CA-8 DC24 Ngày giao hàng: 1-3 days Giá cũ: 2.404.037 ₫ Giá bán: 2.003.364 ₫ Số lượng: Thêm vào giỏ hàng Giao đến Chọn quốc gia Vietnam Vietnam * Khác * Phương pháp vận chuyển Tên Ngày dự kiến giao hàng Giá bán Không có tùy chọn giao hàng nào Áp dụng Custom wishlist được Thêm vào danh sách yêu thích Thêm vào danh sách so sánh Thông Tin Sản Phẩm: H3CA-8 DC24 Thông Tin Kỹ Thuật cơ bản của : Timer Omron H3CA-8H AC100/110/120 Rated supply voltage 24 VDC Time range 0.1 s to 9990 h Input method No-voltage input (open and short-circuit) Control output Time-limit contact: DPDT Display method LCD 3 digit External connection method 8-pin round socket Thông số kỹ thuật chi tiết sản phẩm: Timer Omron H3CA-8H AC100/110/120 Rated supply voltage24 VDCOperating voltage range85 to 110% of rated supply voltagePower consumptionApprox. 1 WTime ranges(Number of ranges)7Time ranges0.1 to 99.9 s1 to 999 s0.1 to 99.9 min1 to 999 min0.1 to 99.9 h1 to 999 h10 to 9990 hInput methodNo-voltage input (open and short-circuit)Output modesA: Power ON delayControl output (Contact output)Time-limit contact: DPDTResistive load: 3 A at 250 VACMinimum applicable load: 10 mA at 5 VDC (failure level: P Reference value)Reset systemSelf-resetPower resetReset time: 0.1 s max.Display methodLCD 3 digitAmbient temperature (Operating)-10 to 55 ℃ (with no icing)Ambient humidity (Operating)35 to 85 %Accuracy of operating time±0.3% ±0.05 s (The values are based on the set value.)Setting error±0.5% ±0.05 s (The values are based on the set value.)Influence of voltage±0.3% ±0.05 s (The values are based on the set value.)Influence of temperature±0.3% ±0.05 s (The values are based on the set value.)Insulation resistance100 MΩ min. (at 500 VDC)Dielectric strengthBetween current carrying metal parts and non-current carrying metal parts: 2000 VAC 50/60 Hz 1 minBetween control output terminals and operating circuit: 2000 VAC 50/60 Hz 1 minBetween non-continuous contacts: 1000 VAC 50/60 Hz 1 minImpulse withstand voltageBetween power terminals: 1 kVBetween current carrying terminals and exposed non-current carrying metal parts: 1.5 kVVibration resistanceDestruction: 10 to 55 Hz, 0.75 mm single amplitude each in 3 directions for 1 hourMalfunction: 10 to 55 Hz, 0.5 mm single amplitude each in 3 directions for 10 minShock resistanceDestruction: 1,000 m/s2, 3 times each in 6 directionsMalfunction: 100 m/s2, 3 times each in 6 directionsLife expectancyElectrical: 100,000 operations min. (3 A at 250 VAC resistive load at 1800 operations/h)Mechanical: 10 million operations min. (under no load at 1,800 operations/h)Degree of protectionIP40Mounting methodFlush mounting / Surface mountingExternal connection method8-pin round socketApplicable socketP2CF-08, P2CF-08-E, P3G-08, PL08Accessory (sold separately)Soft Cover: Y92A-48DHard Cover: Y92A-48BFlush mounting adapter: Y92F-30/Y92F-70/Y92F-71 Cam Kết Chất Lượng và Dịch Vụ Chúng tôi có hơn 35.000 sản phẩm vì vậy hãy liên hệ với chúng tôi Để được tư vấn và check tình trạng hàng bạn nhé! AUTO TECH VN cam kết: 1. Hàng Chính Hãng. 2. Xuất được Hóa đơn VAT. 3. Cấp CO/CQ đầy đủ. 4. Giá cạnh tranh. 5. Sản phẩm bảo hành theo chính sách của hãng.6. Miễn Phí hỗ trợ cài đặt và sử dụng thiết bị. Thông Tin Liên Hệ AUTO TECH VN - AUT.VN ĐT/ Zalo : 0968.053.025 Email: support@aut.vn Email2: sale@aut.vn Địa chỉ: 07 KĐT Flora Mizuki, Đường Số 1, Bình Hưng, Bình Chánh, Hồ Chí Minh Thẻ sản phẩm Timer (1324) , Timers (393) , Omron (52279) , Control Components (121) , Digital Timers (12) , H3CA (12) , H3CA-8 DC24 (1)
