Cảm biến Encoder

Cảm biến Encoder Autonics E60H20-1024-3-T-24

Đường kính trong trục : Ø20mm
Tần số đáp ứng tối đa : 300kHz
Độ phân giải cho phép tối đa : 6000rpm
Mô-men khởi động : Max. 150gf.cm(max. 0.0147N.m)
Độ phân giải : 1024P/R
Ngõ ra điều khiển : Totem pole
Nguồn cấp : 12-24VDC @(=) ±5%(sóng P-P: max. 5%)
Loại kết nối : loại cáp hướng tâm
Cấu trúc bảo vệ : IP50

Cảm biến Encoder Autonics E58H12-1000-6-L-5-C
Shaft inner diameter : Ø12mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 90gf.cm(max. 0.00882N.m)
Resolution : 1000P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial cable connector type
Protection structure : IP50

Cảm biến Encoder Autonics E58H12-1024-6-L-5-C
Shaft inner diameter : Ø12mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 90gf.cm(max. 0.00882N.m)
Resolution : 1024P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial cable connector type
Protection structure : IP50

Cảm biến Encoder Autonics E58H12-1200-6-L-5-C
Shaft inner diameter : Ø12mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 90gf.cm(max. 0.00882N.m)
Resolution : 1200P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial cable connector type
Protection structure : IP50

Cảm biến Encoder Autonics E58H12-1500-6-L-5-C
Shaft inner diameter : Ø12mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 90gf.cm(max. 0.00882N.m)
Resolution : 1500P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial cable connector type
Protection structure : IP50

Cảm biến Encoder Autonics E58H12-1800-6-L-5-C
Shaft inner diameter : Ø12mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 90gf.cm(max. 0.00882N.m)
Resolution : 1800P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial cable connector type
Protection structure : IP50

Cảm biến Encoder Autonics E58H12-2000-6-L-5-C
Shaft inner diameter : Ø12mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 90gf.cm(max. 0.00882N.m)
Resolution : 2000P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial cable connector type
Protection structure : IP50

Cảm biến Encoder Autonics E58H12-2048-6-L-5-C
Shaft inner diameter : Ø12mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 90gf.cm(max. 0.00882N.m)
Resolution : 2048P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial cable connector type
Protection structure : IP50

Cảm biến Encoder Autonics E58H12-2500-6-L-5-C
Shaft inner diameter : Ø12mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 90gf.cm(max. 0.00882N.m)
Resolution : 2500P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial cable connector type
Protection structure : IP50
