Cảm biến Encoder

Cảm biến Encoder Autonics E80H30-100-3-V-24-C
Shaft inner diameter : Ø30mm
Max. response frequency : 200kHz
Max. allowable revolution : 3600rpm
Starting torque : Max. 200gf.cm(max. 0.0196N.m)
Resolution : 100P/R
Control output : Voltage
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial cable connector type
Protection structure : IP50

Cảm biến Encoder Autonics E80H30-60-3-V-24-C
Shaft inner diameter : Ø30mm
Max. response frequency : 200kHz
Max. allowable revolution : 3600rpm
Starting torque : Max. 200gf.cm(max. 0.0196N.m)
Resolution : 60P/R
Control output : Voltage
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial cable connector type
Protection structure : IP50

Cảm biến Encoder Autonics E58SC10-8000-6-L-5
Shaft outer diameter : Ø10mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 40gf.cm(max. 0.00392N.m)
Resolution : 8000P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type
Protection structure : IP50

Cảm biến Encoder Autonics E58SS6-8000-6-L-5
Shaft outer diameter : Ø6mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 40gf.cm(max. 0.00392N.m)
Resolution : 8000P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type
Protection structure : IP50

Cảm biến Encoder  Omron E6C2-CWZ6C 400P/R 2M
Rotary Encoder
Incremental
External Diameter: 50 dia.
NPN Open-collector output
400 P/R
5 to 24 VDC
Phases A/B/Z
Pre-wired model
2 m

Cảm biến Encoder  Omron E6B2-CWZ3E 50P/R 2M
Rotary Encoder
Incremental
External Diameter: 40 dia.
Voltage output (NPN)
50 P/R
5 to 12 VDC
Phases A/B/Z
Pre-wired model
2 m

Cảm biến Encoder  Omron E6C2-CWZ6C 60P/R 2M
Rotary Encoder
Incremental
External Diameter: 50 dia.
NPN Open-collector output
60 P/R
5 to 24 VDC
Phases A/B/Z
Pre-wired model
2 m

Thông tin mô tả sản phẩm: E6B2-CWZ1X 1200P/R 2M

Bộ mã hóa vòng quay tương đối OMRON E6B2-CWZ1X 1200P/R 2M

5VDC
Loại trục
1200 xung

Cảm biến Encoder Autonics E60H20-8192-3-T-24
Shaft inner diameter : Ø20mm
Max. response frequency : 300kHz
Max. allowable revolution : 6000rpm
Starting torque : Max. 150gf.cm(max. 0.0147N.m)
Resolution : 8192P/R
Control output : Totem pole
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial cable type
Protection structure : IP50
