Cảm biến Encoder

Cảm biến Encoder Autonics ENP-111F-024-P
Shaft outer diameter : Ø10mm
Max. response frequency : 20kHz
Max. allowable revolution : 3600rpm
Starting torque : Max. 500gf.cm(max. 0.049N.m)
Resolution : 24P/R
Output specification : Positive logic(PNP)
Rotating direction : CW
Control output : PNP open collector
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type

Cảm biến Encoder Autonics ENP-111R-006-P
Shaft outer diameter : Ø10mm
Max. response frequency : 20kHz
Max. allowable revolution : 3600rpm
Starting torque : Max. 500gf.cm(max. 0.049N.m)
Resolution : 6P/R
Output specification : Positive logic(PNP)
Rotating direction : CCW
Control output : PNP open collector
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type

Cảm biến Encoder Autonics ENP-111R-008-P
Shaft outer diameter : Ø10mm
Max. response frequency : 20kHz
Max. allowable revolution : 3600rpm
Starting torque : Max. 500gf.cm(max. 0.049N.m)
Resolution : 8P/R
Output specification : Positive logic(PNP)
Rotating direction : CCW
Control output : PNP open collector
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type

Cảm biến Encoder Autonics ENP-111R-016-P
Shaft outer diameter : Ø10mm
Max. response frequency : 20kHz
Max. allowable revolution : 3600rpm
Starting torque : Max. 500gf.cm(max. 0.049N.m)
Resolution : 16P/R
Output specification : Positive logic(PNP)
Rotating direction : CCW
Control output : PNP open collector
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type

Cảm biến Encoder Autonics ENP-101F-006-N
Shaft outer diameter : Ø10mm
Max. response frequency : 20kHz
Max. allowable revolution : 3600rpm
Starting torque : Max. 500gf.cm(max. 0.049N.m)
Resolution : 6P/R
Output specification : Negative logic(NPN)
Rotating direction : CW
Control output : NPN open collector
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type

Cảm biến Encoder Autonics ENP-101F-008-N
Shaft outer diameter : Ø10mm
Max. response frequency : 20kHz
Max. allowable revolution : 3600rpm
Starting torque : Max. 500gf.cm(max. 0.049N.m)
Resolution : 8P/R
Output specification : Negative logic(NPN)
Rotating direction : CW
Control output : NPN open collector
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type

Cảm biến Encoder Autonics ENP-101F-012-N
Shaft outer diameter : Ø10mm
Max. response frequency : 20kHz
Max. allowable revolution : 3600rpm
Starting torque : Max. 500gf.cm(max. 0.049N.m)
Resolution : 12P/R
Output specification : Negative logic(NPN)
Rotating direction : CW
Control output : NPN open collector
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type

Cảm biến Encoder Autonics ENP-101F-016-N
Shaft outer diameter : Ø10mm
Max. response frequency : 20kHz
Max. allowable revolution : 3600rpm
Starting torque : Max. 500gf.cm(max. 0.049N.m)
Resolution : 16P/R
Output specification : Negative logic(NPN)
Rotating direction : CW
Control output : NPN open collector
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type

Cảm biến Encoder Autonics ENP-101F-024-N
Shaft outer diameter : Ø10mm
Max. response frequency : 20kHz
Max. allowable revolution : 3600rpm
Starting torque : Max. 500gf.cm(max. 0.049N.m)
Resolution : 24P/R
Output specification : Negative logic(NPN)
Rotating direction : CW
Control output : NPN open collector
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type
