Cảm biến Encoder

Cảm biến Encoder Autonics ENP-101R-006-N
Shaft outer diameter : Ø10mm
Max. response frequency : 20kHz
Max. allowable revolution : 3600rpm
Starting torque : Max. 500gf.cm(max. 0.049N.m)
Resolution : 6P/R
Output specification : Negative logic(NPN)
Rotating direction : CCW
Control output : NPN open collector
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type

Cảm biến Encoder Autonics ENP-101R-008-N
Shaft outer diameter : Ø10mm
Max. response frequency : 20kHz
Max. allowable revolution : 3600rpm
Starting torque : Max. 500gf.cm(max. 0.049N.m)
Resolution : 8P/R
Output specification : Negative logic(NPN)
Rotating direction : CCW
Control output : NPN open collector
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type

Cảm biến Encoder Autonics ENP-101R-012-N
Shaft outer diameter : Ø10mm
Max. response frequency : 20kHz
Max. allowable revolution : 3600rpm
Starting torque : Max. 500gf.cm(max. 0.049N.m)
Resolution : 12P/R
Output specification : Negative logic(NPN)
Rotating direction : CCW
Control output : NPN open collector
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type

Cảm biến Encoder Autonics ENP-101R-016-N
Shaft outer diameter : Ø10mm
Max. response frequency : 20kHz
Max. allowable revolution : 3600rpm
Starting torque : Max. 500gf.cm(max. 0.049N.m)
Resolution : 16P/R
Output specification : Negative logic(NPN)
Rotating direction : CCW
Control output : NPN open collector
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type

Cảm biến Encoder Autonics ENP-101R-024-N
Shaft outer diameter : Ø10mm
Max. response frequency : 20kHz
Max. allowable revolution : 3600rpm
Starting torque : Max. 500gf.cm(max. 0.049N.m)
Resolution : 24P/R
Output specification : Negative logic(NPN)
Rotating direction : CCW
Control output : NPN open collector
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type

Thông tin mô tả sản phẩm: E6B2-CWZ6C 720P/R 2M

Bộ mã hóa vòng quay tương đối OMRON E6B2-CWZ6C 720P/R 2M

5...24VDC
Loại trục
720 xung

Cảm biến Encoder  Omron E6C2-CWZ6C 720P/R 2M
Rotary Encoder
Incremental
External Diameter: 50 dia.
NPN Open-collector output
720 P/R
5 to 24 VDC
Phases A/B/Z
Pre-wired model
2 m

Cảm biến Encoder  Omron E6C3-CWZ3EH 1500P/R 1M
Rugged Rotary Encoder
Incremental
External Diameter: 50 dia.
Voltage output (NPN)
1500 P/R
5 to 12 VDC
Phases A/B/Z
Pre-wired model
1 m
