Cảm biến quang điện

Cảm biến quang điện Autonics BTS200-MDTL

Sensing type : Retroreflective type
Sensing distance : 10~200mm
Sensing target : Opaque material of min. Ø27mm(min. sensing target: opaque material of Ø2mm)
Light source : Red LED(650nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON
Control output : NPN open collector

Cảm biến quang điện Autonics BTS200-MDTD

Sensing type : Retroreflective type
Sensing distance : 10~200mm
Sensing target : Opaque material of min. Ø27mm(min. sensing target: opaque material of Ø2mm)
Light source : Red LED(650nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Dark ON
Control output : NPN open collector

Cảm biến quang điện Autonics BJ300-DDT-C

Sensing type : Diffuse reflective type
Sensing distance : 300mm
Sensing target : Opaque, Translucent material
Light source : Red LED(660nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : NPN open collector

Cảm biến quang điện Autonics BJ300-DDT-C-P

Sensing type : Diffuse reflective type
Sensing distance : 300mm
Sensing target : Opaque, Translucent material
Light source : Red LED(660nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : PNP open collector

Cảm biến quang điện Autonics BJ100-DDT-C

Sensing type : Diffuse reflective type
Sensing distance : 100mm
Sensing target : Opaque, Translucent material
Light source : Infrared LED(850nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : NPN open collector

Cảm biến quang điện Autonics BJ100-DDT-C-P

Sensing type : Diffuse reflective type
Sensing distance : 100mm
Sensing target : Opaque, Translucent material
Light source : Infrared LED(850nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON/Dark ON(set by switch)
Control output : PNP open collector

Cảm biến quang điện Autonics BTS200-MDTL-P
Sensing type : Retroreflective type
Sensing distance : 10~200mm
Sensing target : Opaque material of min. Ø27mm(min. sensing target: opaque material of Ø2mm)
Light source : Red LED(650nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Light ON
Control output : PNP open collector

Cảm biến quang điện Autonics BTS200-MDTD-P
Sensing type : Retroreflective type
Sensing distance : 10~200mm
Sensing target : Opaque material of min. Ø27mm(min. sensing target: opaque material of Ø2mm)
Light source : Red LED(650nm)
Response time : Max. 1ms
Power supply : 12-24VDC @(=) ±10%(ripple P-P: max. 10%)
Operation mode : Dark ON
Control output : PNP open collector

Cảm biến quang điện  Omron E3FA-RN11 2M
Photoelectric Sensor
Retro-reflective type with MSR function
Sensing distance: 0.1 to 4 m (when using E39-R1S)
NPN output
Pre-wired
2 m
