Cầu đấu dây

Cầu đấu dây Autonics ABS-H16TN-PN
Rated voltage : 24VDC @(=) ±10%
Rated load voltage & current : 250VAC~ 3A, 30VDC @(=) 3A
Current consumption : ≤8.5mA/≤13.5mA
Applied relay : NYP24W-K[TAKAMISAWA(Fujitsu)]
Number of relay points : 16-point
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃
Material : CASE: MPPO, BASE: Polyamide 66 (G25%), TERMINAL PIN: Brass

Mua Ngay :

Cầu đấu dây Autonics ABS-HC16TN-NN

Relay áp dụng : NYP24W-K [TAKAMISAWA (Fujitsu)]
Dòng tiêu thụ : ≤ 7.8 mA or ≤ 10.5 mA
Số tiếp điểm relay : 16
Loại terminal : Ốc vít
Khoảng cách giữa các terminal : 7.62 mm

Mua Ngay :

Cầu đấu dây Autonics ABS-S01PA-CN

Điện áp định mức : 24VDC @(=) ±10%
Điện áp và dòng tải định mức : 250VAC~ 3A, 30VDC @(=) 3A
Dòng tiêu thụ : ≤ 8mA
Relay áp dụng : APAN3124 [MATSUSHITA(Panasonic)]
Số tiếp điểm relay : 1 điểm
Môi trường_Nhiệt độ xung quanh : -15 đến 55℃, bảo quản : -25 đến 65℃
Chất liệu : Vỏ & BASE: Polyamide 6, TERMINAL PIN: Brass

Mua Ngay :

Cầu đấu dây Autonics ABS-S01PQ-CN
Rated voltage : 24VDC @(=) ±10%
Rated load voltage & current : 250VAC~ 5A, 30VDC @(=) 5A
Current consumption : ≤20mA
Applied relay : PQ1a-24V [MATSUSHITA(Panasonic)]
Number of relay points : 1-point
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃
Material : CASE & BASE: PA6, TERMINAL PIN: Brass

Mua Ngay :

Cầu đấu dây Autonics ABS-S01R25-CN
Rated voltage : 200/220VAC~
Rated load voltage & current : 250VAC~ 10A, 30VDC @(=) 10A
Current consumption : ≤10mA
Applied relay : G2R-1-S200/(220)VAC [OMRON]
Number of relay points : 1-point
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃
Material : CASE, BASE: PBT, TERMINAL PIN: Brass, Phosphor bronze

Mua Ngay :

Cầu đấu dây Autonics ABS-S01R26-CN
Rated voltage : 100/110VAC~
Rated load voltage & current : 250VAC~ 10A, 30VDC @(=) 10A
Current consumption : ≤15mA
Applied relay : G2R-1-S100/(110)VAC [OMRON]
Number of relay points : 1-point
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃
Material : CASE, BASE: PBT, TERMINAL PIN: Brass, Phosphor bronze

Mua Ngay :

Cầu đấu dây Autonics ABS-S01R2-CN
Rated voltage : 24VDC @(=)
Rated load voltage & current : 250VAC~ 10A, 30VDC @(=) 10A
Current consumption : ≤25mA
Applied relay : G2R-1-S24VDC [OMRON]
Number of relay points : 1-point
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃
Material : CASE, BASE: PBT, TERMINAL PIN: Brass, Phosphor bronze

Mua Ngay :

Cầu đấu dây Autonics ABS-S01R6-CN
Rated voltage : 24VDC @(=) ±10%
Rated load voltage & current : 250VAC~ 5A, 30VDC @(=) 5A
Current consumption : ≤20mA
Applied relay : G6B-1174P-FD-US[OMRON]
Number of relay points : 1-point
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃
Material : CASE & BASE: PA6, TERMINAL PIN: Brass

Mua Ngay :

Cầu đấu dây Autonics ABS-S01TN-CN
Rated voltage : 24VDC @(=) ±10%
Rated load voltage & current : 250VAC~ 3A, 30VDC @(=) 3A
Current consumption : ≤8.5mA
Applied relay : NYP24W-K[TAKAMISAWA(Fujitsu)]
Number of relay points : 1-point
Environment_Ambient temperature : -15 to 55℃, storage: -25 to 65℃
Material : CASE & BASE: PA6, TERMINAL PIN: Brass

Mua Ngay :
