Timer Omron H3CA-A

Name: Timer Omron H3CA-A
SKU: H3CA-A
Price: 670.00 VND
Availability: InStock

Timer Omron H3CA-A
Solid-state Timer
8 operation
Time-limit contact SPDT
Time range: 0.1 s to 9990 h
11-pin
Flush or Surface mounting
24 to 240 VAC/12 to 240 VDC

Mua Ngay :

nhà chế tạo: Omron

SKU: H3CA-A

Ngày giao hàng: 1-3 days

670 ₫

Số lượng:

Timer Omron H3CA-A

Thông số cơ bản

Rated supply voltage	24 to 240 VAC 12 to 240 VDC
Time range	0.1 s to 9990 h
Input method	No-voltage input (open and short-circuit)
Control output	Time-limit contact: SPDT
Display method	LCD 3 digit
External connection method	11-pin round socket

Thông Tin Chi Tiết Sản Phẩm


Rated supply voltage	24 to 240 VAC (50/60 Hz) 12 to 240 VDC (Ripple 20% max. (Single-phase full-wave rectified power sources may be used for 24 to 240 VDC.))
Operating voltage range	90 to 110% of rated supply voltage (21.6 to 264 VAC/10.8 to 264 VDC)
Power consumption	Approx. 0.2 to 4 VA/Approx. 0.2 to 2 W
Time ranges（Number of ranges）	7
Time ranges	0.1 to 99.9 s 1 to 999 s 0.1 to 99.9 min 1 to 999 min 0.1 to 99.9 h 1 to 999 h 10 to 9990 h
Input method	No-voltage input (open and short-circuit)
Output modes	A: ON delay B: Repeat cycle C: Signal ON/OFF delay D: Signal OFF delay E: Interval F: One shot and flicker G: Signal ON/OFF delay H: Signal OFF delay
Control output （Contact output）	Time-limit contact: SPDT Resistive load: 3 A at 250 VAC Minimum applicable load: 10 mA at 5 VDC (failure level: P Reference value)
Reset system	Self-reset/External reset
Power reset	Reset time: 0.5 s max.
Display method	LCD 3 digit
Ambient temperature (Operating)	-10 to 55 ℃ (with no icing)
Ambient humidity (Operating)	35 to 85 %
Accuracy of operating time	±0.3% ±0.05 s (The values are based on the set value.)
Setting error	±0.5% ±0.05 s (The values are based on the set value.)
Influence of voltage	±0.3% ±0.05 s (The values are based on the set value.)
Influence of temperature	±0.3% ±0.05 s (The values are based on the set value.)
Insulation resistance	100 MΩ min. (at 500 VDC)
Dielectric strength	Between current carrying metal parts and non-current carrying metal parts: 2000 VAC 50/60 Hz 1 min Between control output terminals and operating circuit: 2000 VAC 50/60 Hz 1 min Between non-continuous contacts: 1000 VAC 50/60 Hz 1 min
Impulse withstand voltage	Between power terminals: 5 kV Between current carrying terminals and exposed non-current carrying metal parts: 5 kV
Vibration resistance	Destruction: 10 to 55 Hz, 0.75 mm single amplitude each in 3 directions for 1 hour Malfunction: 10 to 55 Hz, 0.5 mm single amplitude each in 3 directions for 10 min
Shock resistance	Destruction: 1,000 m/s², 3 times each in 6 directions Malfunction: 100 m/s², 3 times each in 6 directions
Life expectancy	Electrical: 100,000 operations min. (3 A at 250 VAC resistive load at 1800 operations/h) Mechanical: 10 million operations min. (under no load at 1,800 operations/h)
Degree of protection	IP40
Mounting method	Flush mounting / Surface mounting
External connection method	11-pin round socket
Applicable socket	P2CF-11, P2CF-11-E, P3GA-11, PL11
Accessory (sold separately)	Soft Cover: Y92A-48D Hard Cover: Y92A-48B Flush mounting adapter: Y92F-30/Y92F-70/Y92F-71
Weight	Approx. 110 g
