Cảm biến Encoder

Cảm biến Encoder Autonics E60H20-1024-3-T-5

Đường kính trong trục : Ø20mm
Tần số đáp ứng tối đa : 300kHz
Độ phân giải cho phép tối đa : 6000rpm
Mô-men khởi động : Max. 150gf.cm(max. 0.0147N.m)
Độ phân giải : 1024P/R
Ngõ ra điều khiển : Totem pole
Nguồn cấp : 5VDC @(=) ±5%(sóng P-P: max. 5%)
Loại kết nối : loại cáp hướng tâm
Cấu trúc bảo vệ : IP50

Cảm biến Encoder Autonics E60H20-1024-3-N-24

Đường kính trong trục : Ø20mm
Tần số đáp ứng tối đa : 300kHz
Độ phân giải cho phép tối đa : 6000rpm
Mô-men khởi động : Max. 150gf.cm(max. 0.0147N.m)
Độ phân giải : 1024P/R
Ngõ ra điều khiển : NPN mạch thu hở
Nguồn cấp : 12-24VDC @(=) ±5%(sóng P-P: max. 5%)
Loại kết nối : loại cáp hướng tâm
Cấu trúc bảo vệ : IP50

Cảm biến Encoder Autonics E58SS6-6000-3-T-24
Shaft outer diameter : Ø6mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 40gf.cm(max. 0.00392N.m)
Resolution : 6000P/R
Control output : Totem pole
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type
Protection structure : IP50

Cảm biến Encoder Autonics E58SS6-6000-3-T-5
Shaft outer diameter : Ø6mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 40gf.cm(max. 0.00392N.m)
Resolution : 6000P/R
Control output : Totem pole
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type
Protection structure : IP50

Cảm biến Encoder Autonics E50S8-6000-6-L-5-C
Shaft outer diameter : Ø8mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 70gf.cm(max. 0.00686N.m)
Resolution : 6000P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable connector type
Protection structure : IP50 (IEC standard)

Cảm biến Encoder Autonics E50S8-6000-6-L-5-CR
Shaft outer diameter : Ø8mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 800gf.cm(max. 0.0784N.m)
Resolution : 6000P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial connector type
Protection structure : IP64 (IEC standard)

Cảm biến Encoder Autonics E50S8-6000-6-L-5-CS
Shaft outer diameter : Ø8mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 800gf.cm(max. 0.0784N.m)
Resolution : 6000P/R
Control output : Line Driver
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Radial connector type
Protection structure : IP64 (IEC standard)

Cảm biến Encoder Autonics E58SC10-6000-3-T-24
Shaft outer diameter : Ø10mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 40gf.cm(max. 0.00392N.m)
Resolution : 6000P/R
Control output : Totem pole
Power supply : 12-24VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type
Protection structure : IP50

Cảm biến Encoder Autonics E58SC10-6000-3-T-5
Shaft outer diameter : Ø10mm
Max. response frequency : 300kHz
Max. allowable revolution : 5000rpm
Starting torque : Max. 40gf.cm(max. 0.00392N.m)
Resolution : 6000P/R
Control output : Totem pole
Power supply : 5VDC @(=) ±5%(ripple P-P: max. 5%)
Connection type : Axial cable type
Protection structure : IP50
