Servo Drives
Modbus RTU
Leadshine EL8-RS1500F
Servo drives with power rating from 400W to 1500W
User-configurable I/Os: 10 DI, 6 DO, 3 AI, 2 AO
Equipped with internal regenerative resistor and direct drive holding brake
Position, velocity, torque and hybrid control
New servo functions including Zero Tracking Control (ZTC), Position comparison, Black box, 1-click/1-parameter easy tunings
Safety functions such as Safe Torque Off (STO) with SIL3 grading
Matching motors with power rating from 50W to 1500W
Motors with 23-bit magnetic/optical encoders
Optional holding brake
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Servo Drives
EtherCAT
Leadshine EL8-EC2000F
Servo drives with 2000W power rating
User-configurable I/Os: 8 DI, 3 DO, 2 AI, 2AO and 2 high speed touch probe inputs
Equipped with internal regenerative resistor
Position, velocity and torque loop control
New servo functions including Zero Tracking Control (ZTC), Position comparison, Black box, 1-click/1-parameter easy tunings
Safety functions such as Safe Torque Off (STO) with SIL3 grading
Matching motors with power rating from 50W to 2000W
Motors with 23-bit magnetic/optical encoders
Optional holding brake
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Servo Drives
EtherCAT
Leadshine EL8-EC1000F
Servo drives with 1000W power
User-configurable I/Os: 8 DI, 3 DO, 2 AI, 2AO and 2 high speed touch probe inputs
Equipped with internal regenerative resistor
Position, velocity and torque loop control
New servo functions including Zero Tracking Control (ZTC), Position comparison, Black box, 1-click/1-parameter easy tunings
Safety functions such as Safe Torque Off (STO) with SIL3 grading
Matching motors with power rating from 50W to 1000W
Motors with 23-bit magnetic/optical encoders
Optional holding brake
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Servo Drives
EtherCAT
Leadshine EL7-EC2000N
Servo drive with power rating from 400W to 2000W
User-configurable I/Os: 4 DI, 3 DO and 2 high speed touch probe input DB15 I/O port
USB Type-C tuning port, stable and easy to get
Equipped with internal regenerative resistor
Position, velocity and torque loop control
Servo functions including zero tracking control (ZTC), vibration suppression (Mechanical resonance and end vibration), friction compensation and auto gain adjustments
Matching motors with power rating from 30W to 2000W
Motors with 23-bit magnetic/optical encoders
Optional holding brake
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Servo Drives
EtherCAT
Leadshine EL7-EC1500N
Servo drive with power rating from 400W to 2000W
User-configurable I/Os: 4 DI, 3 DO and 2 high speed touch probe input DB15 I/O port
USB Type-C tuning port, stable and easy to get
Equipped with internal regenerative resistor
Position, velocity and torque loop control
Servo functions including zero tracking control (ZTC), vibration suppression (Mechanical resonance and end vibration), friction compensation and auto gain adjustments
Matching motors with power rating from 30W to 1000W
Motors with 23-bit magnetic/optical encoders
Optional holding brake
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Servo Drives
EtherCAT
Leadshine EL7-EC1000NT
Servo drive with power rating from 750W to 7500W
User-configurable I/Os: 4 DI, 3 DO and 2 high speed touch probe inputs
Equipped with internal regenerative resistor
Position, velocity and torque loop control
Servo functions including zero tracking control (ZTC), vibration suppression (Mechanical resonance and end vibration), friction compensation and auto gain adjustments, etc
Matching motors with power rating from 750W to 7500W
Motors with 23-bit magnetic/optical encoders
Optional holding brake
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Closed Loop Stepper Motors
CS-M Series
Leadshine CS-M23445
2 phase, NEMA 34 frame size
109 mm (4.29 inch) long
6 A phase current
4.5 N.m (638 oz-in) holding torque
14 mm (0.551 inch) shaft size
Integrated 1,000 line (4,000 count/revolution) quadrature rotary encoder
High precision, low motor heating, and low vibration
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Closed Loop Stepper Motors
CS-M Series
Leadshine CS-M234120
2 phase, NEMA 34 frame size
158 mm (6.22 inch) long
6 A phase current
12 N.m (1700 oz-in) holding torque
14 mm (0.551 inch) shaft size
Integrated 1,000 line (4,000 count/revolution) quadrature rotary encoder
High precision, low motor heating, and low vibration
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Closed Loop Stepper Motors
CS-M Series
Leadshine CS-M22326
2 phase, NEMA 23 frame size
104 mm (4.09 inch) long
5 A phase current
2.6 N.m (369 oz-in) holding torque
8 mm (0.315 inch) shaft size
Integrated 1,000 line (4,000 count/revolution) quadrature rotary encoder
High precision, low motor heating, and low vibration
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
