Closed Loop Stepper Motors
CS-M Series
Leadshine CS-M22313
2 phase, NEMA 23 frame size
75 mm (2.95 inch) long
4 A phase current
1.3 N.m (185 oz-in) holding torque
8 mm (0.315 inch) shaft size
Integrated 1,000 line (4,000 count/revolution) quadrature rotary encoder
High precision, low motor heating, and low vibration
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Closed Loop Stepper Motors
CS-M Series
Leadshine CS-M21706
2 phase, NEMA 17 frame size
70 mm (2.76 inch) long
2.5 A phase current
0.6 N.m (85 oz-in) holding torque
5 mm (0.197 inch) shaft size
Integrated 1,000 line (4,000 count/revolution) quadrature rotary encoder
High precision, low motor heating, and low vibration
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Stepper Motors
CM Series
Leadshine 42CM04
2 phase, NEMA 17 frame size
40 mm (1.57 inch) long
1.5 A phase current
0.4 N.m (57 oz-in) holding torque
5 mm (0.197 inch) shaft size
Built with high quality materials including bearings and shaft made by Japanese manufacturers
High precision, low motor heating, and low vibration
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Stepper Motors
CM Series
Leadshine 42CM02
2 phase, NEMA 17 frame size
33 mm (1.30 inch) long
1.5 A phase current
0.21 N.m (30 oz-in) holding torque
5 mm (0.197 inch) shaft size
Built with high quality materials including bearings and shaft made by Japanese manufacturers
High precision, low motor heating, and low vibration
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Stepper Motors
CM Series
Leadshine 28CM006
2 phase, NEMA 11 frame size
32 mm (1.26 inch) long
1.2 A phase current
0.06 N.m (9 oz-in) holding torque
4.5 mm (0.177 inch) shaft size
Built with high quality materials including bearings and shaft made by Japanese manufacturers
High precision, low motor heating, and low vibration
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Stepper Motors
CM Series
Leadshine 20CM003
2 phase, NEMA 8 frame size
33 mm (1.30 inch) long
0.6 A phase current
0.03 N.m (4 oz-in) holding torque
4 mm (0.157 inch) shaft size
Built with high quality materials including bearings and shaft made by Japanese manufacturers
High precision, low motor heating, and low vibration
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Servo Drives
EL6 Series
Leadshine EL6-RS750P
Servo drive power rating: 750W
User-configurable I/Os: 8 DI, 5 DO
Pulse input: High speed – 4MHz, Low speed – 200kHz (24V), 500kHz(5V)
Equipped with internal regenerative resistor
Position, velocity, torque and hybrid loop control
Servo functions including Zero Tracking Control (ZTC), vibration suppression, friction compensation, 16 configurable PR paths and easy servo tunings.
Matching motors with power rating from 50W to 750W
Motors with 23-bit magnetic/optical encoders
Optional holding brake
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Closed Loop Stepper Drives
Modbus RTU
Leadshine CS2RS-D507
CS2RS Series are closed loop stepper drive based on standard Modbus RTU protocol, using RS485 communication can network up to 31 axes, built-in PR feature with 16-segment position table (PR Mode). They can not only solve the problem of step loss in the open loop stepper system, but also can save additional controllers in most of point-to-point applications, to greatly enhance system reliability and reduce the cost. CS2RS Series also support the feature of teaching, the operation modes of Profile Position, Profile Velocity and Homing. CS2RS-D503 can power 2-phase NEMA 17, 23, 24 stepper motors with 1000 ppr to 5000 ppr incremental encoders.
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Closed Loop Stepper Drives
EtherCAT
Leadshine CS3E-D507
The newly released CS3E-D507 supports CANopen over EtherCAT (CoE) control and CiA 402 operating modes including Profile Position (PP), Profile Velocity (PV), Homing (HM) and Cyclic Synchronous Position (CSP). The product can be matched with many brands of EtherCAT controller/PLC such as Beckhoff, Omron, Trio, Keneyce etc.
The CS3E-D507 is able to power 2 phase and 4 phase NEMA 23 and 24 stepper motors with incremental encoders. It is highly reliable and affordable and performs excellently in many industrial applications
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
