Servo Drives
EtherCAT
Leadshine EL8-EC750F
Servo drives with power rating from 400W to 1000W
User-configurable I/Os: 8 DI, 3 DO, 2 AI, 2AO and 2 high speed touch probe inputs
Equipped with internal regenerative resistor
Position, velocity and torque loop control
New servo functions including Zero Tracking Control (ZTC), Position comparison, Black box, 1-click/1-parameter easy tunings
Safety functions such as Safe Torque Off (STO) with SIL3 grading
Matching motors with power rating from 50W to 1000W
Motors with 23-bit magnetic/optical encoders
Optional holding brake
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Closed Loop Stepper Motors
CS-M Series
Leadshine CS-M22430
2 phase, NEMA 24 (60mm) frame size
107 mm (4.21 inch) long
5 A phase current
3 N.m (425 oz-in) holding torque
8 mm (0.315 inch) shaft size
Integrated 1,000 line (4,000 count/revolution) quadrature rotary encoder
High precision, low motor heating, and low vibration
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Closed Loop Stepper Drives
Modbus RTU
Leadshine CS2RS-D503
CS2RS Series are closed loop stepper drive based on standard Modbus RTU protocol, using RS485 communication can network up to 31 axes, built-in PR feature with 16-segment position table (PR Mode). They can not only solve the problem of step loss in the open loop stepper system, but also can save additional controllers in most of point-to-point applications, to greatly enhance system reliability and reduce the cost. CS2RS Series also support the feature of teaching, the operation modes of Profile Position, Profile Velocity and Homing. CS2RS-D503 can power 2-phase NEMA 8, 11, 14, 17 stepper motors with 1000 ppr to 5000 ppr incremental encoders.
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Closed Loop Stepper Drives
EtherCAT
Leadshine CS3E-D503E
The newly released CS3E-E series drives support CANopen over EtherCAT (CoE) control and CiA 402 operating modes including Profile Position (PP), Profile Velocity (PV), Homing (HM) and Cyclic Synchronous Position (CSP). The products can be matched with many brands of EtherCAT controller/PLC such as Beckhoff,Omron, Trio, Keneyce, etc.
The CS3E-E series is highly reliable and affordable and performs excellently in many industrial applications such as solar equipment, textile, civil, robotics, power generation equipment, 3C,packaging...
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Closed Loop Stepper Drives
EtherCAT
Leadshine CS3E-D503B
The newly released CS3E-B series drives support CANopen over EtherCAT (CoE) control and CiA 402 operating modes including Profile Position (PP), Profile Velocity (PV), Homing (HM) and Cyclic Synchronous Position (CSP). The products can be matched with many brands of EtherCAT controller/PLC such as Beckhoff,Omron, Trio, Keneyce, etc.
The CS3E-B series is highly reliable and affordable and performs excellently in many industrial applications such as solar equipment, textile, civil, robotics, power generation equipment, 3C,packaging...
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Closed Loop Stepper Drives
EtherCAT
Leadshine CS3E-D503
The newly released CS3E-D503 supports CANopen over EtherCAT (CoE) control and CiA 402 operating modes including Profile Position (PP), Profile Velocity (PV), Homing (HM) and Cyclic Synchronous Position (CSP). The product can be matched with many brands of EtherCAT controller/PLC such as Beckhoff, Omron, Trio, Keneyce etc.
The CS3E-D503 is able to power 2 phase and 4 phase NEMA 8,11, 14 and 17 stepper motors with incremental encoders. It is highly reliable and affordable and performs excellently in many industrial applications
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
Closed Loop Stepper Drives
CS Series
Leadshine CS-D507E
The CS series consists of ES seasy servo drives adopting Leadshine latest advanced closed loop control technology. Those drives are highly reliable with good performance and highly competitive cost. They can power a wide range of closed loop stepper motors from NEMA 8 to NEMA 34 (model dependent) with incremental encoders. CS series drives are easy to configure and setup.
Xuất xứ Trung Quốc, CO, CQ đầy đủ
Bảo hành 1 năm, có đổi mới
0968.053.025
